Single Row Deep Groove Ball Bearings 6309-2Z/LHT23

Single Row Deep Groove Ball Bearings 6309-2Z/LHT23

The 6309-2Z/LHT23 is a single-row deep groove ball bearing with a 45mm bore and 100mm outer diameter, crafted from sturdy chrome steel for durability. It supports radial loads up to 11915 lbf and operates smoothly at speeds up to 6700 RPM.

Shielded on both sides, it keeps contaminants out while maintaining easy access for lubrication. The bearing performs reliably in temperatures ranging from -30°C to 120°C.

With a width of 25mm, it’s compact yet robust for its size. Compliant with RoHS and REACH standards, it’s a safe choice for various applications.

Ideal for machinery like pumps or electric motors where radial load handling and long service life are key. Its design ensures stability and low maintenance.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number 6309-2Z/LHT23
  • Brand TFL
  • Interchangeable SKF
  • System of Measurement Metric
  • For Load Direction Radial
  • Construction Single Row
  • Bearing Type Ball
  • Seal Type Shielded
  • Tolerance Class ABEC 1 | ISO P0
  • Radial Clearance Trade No CN
  • Bore Dia 45 mm
  • Bore Dia Tolerance -0.012mm to 0
  • Outer Dia 100 mm
  • Outer Dia Tolerance -0.015mm to 0
  • Width 25 mm
  • Width Tolerance -0.120mm to 0
  • Ring Material Chrome Steel
  • Ball Material Chrome Steel
  • Cage Material Chrome Steel
  • ROHS Compliant
  • REACH Compliant
  • Temperature Range -30°to 120 °C
  • Dynamic Radial Load 11915 lbf
  • Static Radial Load 7194 lbf
  • Max Speed 6700 rpm
  • Weight 811 g
  • price（$） 15.057
Single Row Deep Groove Ball Bearings 6309-2Z/LHT23 dimension drawing
Download DWG Download PDF

Features

Performance Features of 6309-2Z/LHT23 Bearing

6309-2Z/LHT23 Bearing is designed with chrome steel rings and balls, offering strong resistance to radial loads.
Its dynamic radial load capacity reaches 11915 lbf, ensuring reliable performance in various applications.

The shielded design of 6309-2Z/LHT23 Bearing protects against contaminants, extending its service life.
With a maximum speed of 6,700 rpm, it balances durability and efficiency for smooth operation.

6309-2Z/LHT23 Bearing operates in temperatures from -30° to 120°C, making it suitable for diverse environments.
Its chrome steel cage ensures stability and reduces wear, even under heavy loads.

The ABEC 1 tolerance class of 6309-2Z/LHT23 Bearing provides consistent performance for precision tasks.
Its compact size (45 mm×100 mm×25 mm) makes it ideal for space-constrained applications.

Application

Common Applications of 6309-2Z/LHT23 Bearing
In industrial settings, 6309-2Z/LHT23 Bearing is commonly used in machinery like pumps and electric motors, where its shielded design helps keep contaminants out. The chrome steel construction ensures durability even in demanding environments.

How Does 6309-2Z/LHT23 Bearing Improve Performance?
For automotive applications, 6309-2Z/LHT23 Bearing enhances reliability in components such as alternators and wheel hubs. Its metric sizing and radial load capacity make it a versatile choice for various vehicle models.

Ideal for Precision: 6309-2Z/LHT23 Bearing
In medical devices, 6309-2Z/LHT23 Bearing provides smooth operation for equipment like centrifuges and lab instruments. The shielded seals help maintain cleanliness, which is essential in sensitive environments.

Automotive vs Industrial: Applications of 6309-2Z/LHT23 Bearing
While 6309-2Z/LHT23 Bearing excels in automotive systems like transmissions, it’s equally effective in industrial gearboxes. Its balanced load handling and temperature tolerance make it suitable for diverse uses.

Where Is 6309-2Z/LHT23 Bearing Used?
You’ll often find 6309-2Z/LHT23 Bearing in household appliances like washing machines, where its quiet operation and long lifespan are appreciated. The shielded design also reduces maintenance needs.
