Single Row Deep Groove Ball Bearings 16013

Single Row Deep Groove Ball Bearings 16013

The 16013 is a single row deep groove ball bearing with a 65mm bore and 100mm outer diameter, crafted from sturdy chrome steel. It handles radial loads up to 4609 lbf and operates smoothly at speeds up to 5000 RPM.

Its open design simplifies lubrication, while the stainless steel cage enhances durability. Suitable for temperatures ranging from -30°C to 110°C, it’s versatile for various conditions.

This model is interchangeable with SKF bearings, offering a reliable replacement option. Perfect for applications like electric motors or pumps where radial loads are common.

Weighing 290g, it’s lightweight yet robust. Compliant with RoHS and REACH standards, ensuring safe and eco-friendly use.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number 16013
  • Brand TFL
  • Interchangeable SKF
  • System of Measurement Metric
  • For Load Direction Radial
  • Construction Single Row
  • Bearing Type Ball
  • Seal Type Open
  • Tolerance Class ABEC-1
  • Radial Clearance Trade No CN
  • Bore Dia 65 mm
  • Bore Dia Tolerance -0.015mm to 0
  • Outer Dia 100 mm
  • Outer Dia Tolerance -0.015mm to 0
  • Width 11 mm
  • Width Tolerance -0.150mm to 0
  • Ring Material Chrome Steel
  • Ball Material Chrome Steel
  • Cage Material Stainless Steel
  • Lubrication Required
  • REACH Compliant
  • Temperature Range -30° to 110 °C
  • Dynamic Radial Load 4609 lbf
  • Static Radial Load 4204 lbf
  • Max Speed 5000 rpm
  • Weight 290 g
  • price（$） 17.136
Single Row Deep Groove Ball Bearings 16013 dimension drawing
Download DWG Download PDF

Features

Performance Features of 16013 Bearing

16013 Bearing is built with chrome steel rings and balls, offering strong resistance to radial loads.
Its dynamic radial load capacity reaches 4609 lbf, ensuring reliable performance in various applications.

The stainless steel cage maintains ball alignment, reducing wear and extending the bearing’s life.
With a maximum speed of 5,000 rpm, it provides a good balance between durability and efficiency.

16013 Bearing operates smoothly in temperatures ranging from -30° to 110°C, making it versatile.
Its open design simplifies lubrication, ensuring consistent performance over time.

The ABEC-1 tolerance class ensures reliable precision for general industrial use.
At 290 grams, it remains lightweight while handling substantial loads.

Application

Industrial Uses of 16013 Bearing
The 16013 Bearing is commonly used in industrial machinery like pumps and electric motors, where its radial load capacity ensures smooth operation. Its open design simplifies lubrication, making maintenance straightforward for busy workshops.

What Makes 16013 Bearing a Preferred Choice?
With its chrome steel construction, 16013 Bearing offers reliable performance in automotive applications such as alternators and small gearboxes. The ABEC-1 tolerance provides a good balance of precision and affordability for general machinery.

Built for Heavy-Duty Use: 16013 Bearing
In conveyor systems, 16013 Bearing handles continuous radial loads efficiently, thanks to its sturdy single-row design. The stainless steel cage adds durability, making it suitable for dusty or humid environments.

Automotive vs Industrial: Applications of 16013 Bearing
While 16013 Bearing works well in car components like fans and clutches, it’s equally at home in factory equipment. Its 65 mm bore fits standard shafts, offering versatility across different sectors.

Where Is 16013 Bearing Used?
You’ll find 16013 Bearing in household appliances like washing machines, where its compact size and radial load support are ideal. The temperature range also ensures stable performance under everyday conditions.
