Single Row Deep Groove Ball Bearings 16007/W64

Single Row Deep Groove Ball Bearings 16007/W64

The 16007/W64 is a single-row deep groove ball bearing with a 35mm bore and 62mm outer diameter, crafted from sturdy chrome steel for reliable performance. It supports radial loads up to 2743 lbf and operates smoothly at speeds up to 8400 RPM.

Its open design and solid oil lubrication ensure low maintenance, while the chrome steel cage enhances durability. The bearing functions well in temperatures ranging from -30°C to 120°C.

This model is interchangeable with SKF bearings, offering a cost-effective alternative for replacements. Suitable for applications like electric motors or small machinery where radial loads are prevalent.

Weighing only 100g, it’s lightweight yet robust. Compliant with RoHS and REACH standards, making it safe for various industrial uses.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number 16007/W64
  • Brand TFL
  • Interchangeable SKF
  • System of Measurement Metric
  • For Load Direction Radial
  • Construction Single Row
  • Bearing Type Ball
  • Seal Type Open
  • Tolerance Class ABEC 1 | ISO P0
  • Radial Clearance Trade No CN
  • Bore Dia 35 mm
  • Bore Dia Tolerance -0.012mm to 0
  • Outer Dia 62 mm
  • Outer Dia Tolerance -0.013mm to 0
  • Width 9 mm
  • Width Tolerance -0.120mm to 0
  • Ring Material Chrome Steel
  • Ball Material Chrome Steel
  • Cage Material Chrome Steel
  • Lubrication Soild Oil
  • ROHS Compliant
  • REACH Compliant
  • Temperature Range -30°to 120 °C
  • Dynamic Radial Load 2743 lbf
  • Static Radial Load 1978 lbf
  • Max Speed 8400 rpm
  • Weight 100 g
  • price（$） 12.15
Single Row Deep Groove Ball Bearings 16007/W64 dimension drawing
Download DWG Download PDF

Features

How Does 16007/W64 Bearing Reduce Friction?

16007/W64 Bearing features a single row deep groove design, optimised for smooth radial load distribution.
Its chrome steel construction ensures durability while reducing friction during operation.

The solid oil lubrication maintains consistent performance, even at speeds up to 8,400 rpm.
With a dynamic radial load capacity of 2743 lbf, it balances efficiency and reliability.

Designed for temperatures from -30°C to 120°C, it adapts well to varying working conditions.
The open seal type allows for easy maintenance, keeping operational costs low.

Application

Common Applications of 16007/W64 Bearing
16007/W64 Bearing is widely used in industrial machinery, such as electric motors and pumps, where its radial load capacity ensures smooth operation. The open design and solid oil lubrication make it suitable for environments where maintenance access is limited.

In automotive applications, 16007/W64 Bearing can be found in components like alternators and water pumps, providing reliable performance under varying speeds. Its chrome steel construction offers durability, even in demanding conditions.

For household appliances, 16007/W64 Bearing is often used in washing machines and fans, where its quiet operation and long lifespan are appreciated. The metric sizing ensures compatibility with a variety of European and Asian models.

Automation systems benefit from 16007/W64 Bearing in robotic arms and conveyor belts, where precision and reliability are key. The ABEC 1 tolerance class ensures consistent performance in these high-precision applications.
