Drawn Cup Needle Roller Bearings SCE2620

Drawn Cup Needle Roller Bearings SCE2620

The SCE2620 is a drawn cup needle roller bearing with a 1.625-inch bore and 2-inch outer diameter, crafted from sturdy steel for reliable performance. It handles radial loads up to 11465 lbf and operates smoothly at speeds up to 6200 RPM.
Its open-end design and press-fit mounting make installation straightforward, while the steel cage ensures durability. The bearing requires regular lubrication for optimal performance.
Suitable for temperatures between -20°C and 110°C, this model is interchangeable with INA bearings. Ideal for applications like automotive components or industrial machinery where radial loads are common.
Compliant with RoHS standards, it’s a practical choice for replacements or new installations. Its compact width of 1.25 inches fits well in tight spaces.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number SCE2620
  • Brand TFL
  • Interchangeable INA
  • Bore Dia 1.625"
  • Bore Dia Tolerance Refer to note on the right drawing
  • Outer Dia 2"
  • Outer Dia Tolerance Not Rated
  • Width 1.25"
  • Width Tolerance -0.01" to 0"
  • System of Measurement Inch
  • Bearing Type Roller
  • Roller Bearing Type Needle
  • For Load Direction Radial
  • Construction Single Row
  • Seal Type Open
  • Series Open End
  • Ring Material Steel
  • Ball Material Steel
  • Cage Material Steel
  • Dynamic Radial Load 11465 lbf
  • Static Radial Load 21806 lbf
  • Lubrication Required
  • Shaft Mount Type Press Fit
  • Temperature Range -20 to 110 °C
  • RoHS Compliant
  • Max Speed 6200 rpm
  • Weight 110 g
Drawn Cup Needle Roller Bearings SCE2620 dimension drawing
Download DWG Download PDF

Features

How Does SCE2620 Bearing Handle Heavy Loads?
SCE2620 Bearing is built with steel rings and needles, offering robust resistance to heavy radial loads.
Its dynamic radial load capacity reaches 11465 lbf, making it suitable for demanding industrial applications.
The open-end design of SCE2620 Bearing allows for easy press-fit installation, saving time and effort.
With a maximum speed of 6200 rpm, it delivers reliable performance under high-speed conditions.
SCE2620 Bearing operates efficiently within a temperature range of -20 to 110°C, ensuring versatility.
Regular lubrication ensures smooth operation and extends the bearing’s service life.

Application

Industrial Uses of SCE2620 Bearing
SCE2620 Bearing is commonly used in industrial machinery where space is limited but high radial load capacity is needed, such as in compact gearboxes and conveyor systems. Its steel construction ensures durability even in demanding environments.
In automotive applications, SCE2620 Bearing fits well in transmission systems and steering mechanisms, providing reliable performance under high radial loads. The press-fit design makes installation straightforward, saving time during assembly.
For automation equipment, SCE2620 Bearing’s open-end design allows easy integration into robotic arms and linear motion systems. Its high-speed capability ensures smooth operation in repetitive tasks.
Where Is SCE2620 Bearing Used?
You’ll often find SCE2620 Bearing in agricultural machinery, where its robust design handles heavy loads in equipment like harvesters and tractors. The inch sizing makes it compatible with many North American machines.
In power tools, SCE2620 Bearing supports high-speed operations, such as in drills and grinders. Its steel cage provides stability, reducing wear over time.
Built for Heavy-Duty Use: SCE2620 Bearing
SCE2620 Bearing excels in construction equipment, where its radial load capacity handles the stress of cranes and excavators. The open seal allows for easy relubrication, extending service life.
For printing machinery, SCE2620 Bearing’s precision ensures consistent performance in high-speed rollers. Its compact size is ideal for tight spaces within the equipment.
Automotive vs Aerospace: Applications of SCE2620 Bearing
In automotive systems, SCE2620 Bearing is trusted for clutch assemblies and differential units, offering reliable performance under stress. The steel construction resists wear in high-friction areas.
For aerospace applications, SCE2620 Bearing’s lightweight yet sturdy design suits auxiliary equipment like landing gear mechanisms. Its temperature range ensures stability in varying conditions.
