Thin Section Ball Bearings 63800zz

Thin Section Ball Bearings 63800zz

The 63800zz is a compact thin-section ball bearing, measuring 10mm by 19mm by 7mm, crafted from durable chrome steel. It handles radial loads up to 387 lbf and spins smoothly at speeds up to 40,000 RPM.

Its shielded design keeps dust out while the stainless steel cage ensures reliable performance. The bearing operates well in temperatures from -30°C to 110°C and requires lubrication for optimal use.

With a lightweight design at just 7.4g, it’s easy to handle and install. Ideal for applications like small motors or precision instruments where space is limited.

Compliant with RoHS and REACH standards, it’s a safe and practical choice for various industrial needs.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number 63800zz
  • Brand TFL
  • Bore Dia 10 mm
  • Bore Dia Tolerance -0.008mm to 0
  • Outer Dia 19 mm
  • Outer Dia Tolerance -0.009mm to 0
  • Width 7 mm
  • Width Tolerance -0.120mm to 0
  • Radial Clearance 0.003mm to 0.018mm
  • System of Measurement Metric
  • Bearing Type Ball
  • For Load Direction Radial
  • Construction Single Row
  • Seal Type Shielded
  • Tolerance Class ABEC-1
  • Radial Clearance Trade No C0
  • Ring Material Chrome Steel
  • Ball Material Chrome Steel
  • Cage Material Stainless Steel
  • Dynamic Radial Load 387 lbf
  • Static Radial Load 189 lbf
  • Temperature Range -30°C to 110 °C
  • Lubrication Required
  • RoHS Compliant
  • REACH Compliant
  • Max Speed 40000 rpm
  • Weight 7.4 g
  • Price（$） 3.2
Thin Section Ball Bearings 63800zz dimension drawing
Download DWG Download PDF

Features

Performance Features of 63800zz Bearing

63800zz Bearing features a compact design with dimensions of 10 mm×19 mm×7 mm, making it ideal for space-constrained applications.
The shielded construction protects against contaminants while maintaining smooth operation.

With a dynamic radial load capacity of 387 lbf, 63800zz Bearing handles moderate loads efficiently.
Its chrome steel rings and balls ensure durability, even in demanding conditions.

The ABEC-1 tolerance class and C0 radial clearance provide reliable precision for various applications.
A maximum speed of 40,000 rpm allows for high-speed performance without compromising stability.

63800zz Bearing operates within a temperature range of -30°C to 110°C, suitable for diverse environments.
Regular lubrication ensures long-lasting performance and reduces wear over time.

Application

Where Is 63800zz Bearing Used?

You’ll often spot 63800zz Bearing in compact machinery where space is tight but smooth rotation matters, like small electric motors or precision instruments. Its shielded design keeps dust out while maintaining low friction.

In robotics, 63800zz Bearing works well in joint assemblies due to its lightweight build and reliable radial load capacity. The ABEC-1 tolerance ensures consistent movement for repetitive tasks.

For office equipment like printers, 63800zz Bearing helps guide paper feed mechanisms quietly and efficiently. The chrome steel construction handles daily wear without losing performance.
