Stainless Steel Deep Groove Ball Bearings W 606-2RS1

Stainless Steel Deep Groove Ball Bearings W 606-2RS1

The W 606-2RS1 is a compact stainless steel deep groove ball bearing, measuring 6mm by 17mm by 6mm. It handles radial loads up to 438 lbf and spins smoothly at speeds up to 26,000 RPM.

Its sealed design keeps grease in and dirt out, making it low-maintenance. The all-stainless construction ensures corrosion resistance and durability.

This bearing works well in temperatures from -30°C to 120°C, suitable for damp or harsh environments. It’s interchangeable with SKF models for easy replacement.

Ideal for small machinery, electric motors, or appliances where space is limited. Weighing just 5.8 grams, it’s lightweight yet robust for its size. Compliant with RoHS and REACH standards.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number W 606-2RS1
  • Brand TFL
  • Interchangeable SKF
  • Bore Dia 6 mm
  • Bore Dia Tolerance -0.008mm to 0
  • Outer Dia 17 mm
  • Outer Dia Tolerance -0.008mm to 0
  • Width 6 mm
  • Width Tolerance -0.12mm to 0
  • System of Measurement Metric
  • Bearing Type Ball
  • For Load Direction Radial
  • Construction Single Row
  • Seal Type Sealed
  • Tolerance Class P0
  • Radial Clearance Trade No CN
  • Ring Material Stainless Steel
  • Ball Material Stainless Steel
  • Cage Material Stainless Steel
  • Dynamic Radial Load 438 lbf
  • Static Radial Load 187 lbf
  • Temperature Range -30° to 120 °C
  • Lubrication Grease
  • RoHS Compliant
  • REACH Compliant
  • Max Speed 26000 rpm
  • Weight 0.0058 kg
  • Price（$） 2.15
Stainless Steel Deep Groove Ball Bearings W 606-2RS1 dimension drawing
Download DWG Download PDF

Features

Why Choose W 606-2RS1 Bearing for Precision Tasks?

W 606-2RS1 Bearing features a sealed design, protecting it from dust and moisture for consistent performance.
Its stainless steel construction ensures corrosion resistance, making it suitable for various environments.

The bearing handles dynamic radial loads up to 438 lbf, providing reliable operation in precision applications.
With a maximum speed of 26,000 rpm, it offers smooth and efficient performance.

W 606-2RS1 Bearing’s compact size (6 mm×17 mm×6 mm) makes it ideal for space-constrained installations.
The grease lubrication reduces maintenance needs, ensuring long-term reliability.

Application

Where Is W 606-2RS1 Bearing Used?
W 606-2RS1 Bearing is commonly found in small electric motors, such as those used in household appliances like fans and blenders. Its compact size and sealed design make it ideal for protecting against dust and moisture.

In automation equipment, W 606-2RS1 Bearing ensures smooth operation in components like conveyor rollers and robotic arms. The stainless steel construction provides good resistance to corrosion, extending its lifespan in demanding environments.

For medical devices, W 606-2RS1 Bearing is often used in portable diagnostic tools due to its reliability and low maintenance requirements. The grease lubrication helps maintain quiet operation, which is essential in sensitive settings.

In consumer electronics, W 606-2RS1 Bearing supports precise movements in devices like printers and scanners. Its metric sizing ensures compatibility with a variety of international designs.
