Snap Ring Groove Ball Bearings 6205-2RSNRJEM/C3

Snap Ring Groove Ball Bearings 6205-2RSNRJEM/C3

The 6205-2RSNRJEM/C3 is a sealed snap ring groove ball bearing with a 25mm bore and 52mm outer diameter, crafted from durable chrome steel. It handles radial loads up to 3147 lbf and spins smoothly at speeds up to 13,000 RPM.

Its sealed design keeps dirt out and grease in, while the snap ring ensures secure fitting. The C3 clearance allows for slight thermal expansion, making it reliable under varying temperatures.

This bearing is interchangeable with SKF models, ideal for replacements in machinery like electric motors or pumps. It operates well in temperatures from -30°C to 120°C.

Weighing just 128g, it’s lightweight yet sturdy. Compliant with RoHS and REACH standards, it’s a safe choice for industrial applications.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number 6205-2RSNRJEM/C3
  • Brand TFL
  • Interchangeable SKF
  • Bore Dia 25 mm
  • Bore Dia Tolerance -0.01mm to 0
  • Outer Dia 52 mm
  • Outer Dia Tolerance -0.013mm to 0
  • Width 15 mm
  • Width Tolerance -0.120mm to 0
  • Outside Diameter Of Snap Ring 57.9 mm
  • Width Of Snap Ring 1.12 mm
  • System of Measurement Metric
  • For Load Direction Radial
  • Construction Single Row
  • Bearing Type Ball
  • Seal Type Sealed
  • Locating Feature Bearing Outer Ring Snap Ring (fitted)
  • Tolerance Class ABEC 1 | ISO P0
  • Radial Clearance Trade No C3
  • Ring Material Chrome Steel
  • Ball Material Chrome Steel
  • Cage Material Chrome Steel
  • Dynamic Radial Load 3147 lbf
  • Static Radial Load 1765 lbf
  • Temperature Range -30°to 120 °C
  • ROHS Compliant
  • REACH Compliant
  • Max Speed 13000 rpm
  • Weight 128 g
Snap Ring Groove Ball Bearings 6205-2RSNRJEM/C3 dimension drawing
Download DWG Download PDF

Features

How Does 6205-2RSNRJEM/C3 Bearing Reduce Friction?

6205-2RSNRJEM/C3 Bearing features a sealed design, preventing contaminants from entering and reducing friction.

The chrome steel construction ensures smooth operation, even under high radial loads up to 3147 lbf.

With a maximum speed of 13,000 rpm, it offers reliable performance in various applications.

The snap ring groove on the outer ring provides secure fitting, enhancing stability during operation.

Application

Industrial Uses of 6205-2RSNRJEM/C3 Bearing
This bearing is commonly used in conveyor systems and industrial fans, where its sealed design keeps contaminants out. The snap ring feature ensures secure mounting, reducing maintenance needs in dusty environments.

Where Is 6205-2RSNRJEM/C3 Bearing Used?
You’ll find it in automotive applications like electric motors and pumps, thanks to its reliable radial load handling. The C3 clearance allows for slight thermal expansion, making it suitable for variable temperatures.

Perfect Fit for Automation: 6205-2RSNRJEM/C3 Bearing
In robotic arms and automated machinery, this bearing offers smooth rotation with minimal friction. Its chrome steel construction ensures long-lasting performance even with frequent use.

Light-Duty vs Heavy-Duty: Best Uses for 6205-2RSNRJEM/C3 Bearing
While it handles light loads in printers and small appliances, it’s also robust enough for agricultural equipment. The sealed design protects against dirt and moisture in both scenarios.

Medical vs Industrial: Where 6205-2RSNRJEM/C3 Bearing Excels
In medical devices like lab centrifuges, its precision is key, while in industrial gearboxes, durability takes priority. The bearing’s versatility makes it a go-to for both fields.
