Single Row Deep Groove Ball Bearings 61905/W64

Single Row Deep Groove Ball Bearings 61905/W64

The 61905/W64 is a compact single-row deep groove ball bearing, measuring 25mm by 42mm by 9mm, crafted from durable chrome steel. It handles radial loads up to 1578 lbf and spins smoothly at speeds up to 22,000 RPM.

Its open design and solid oil lubrication ensure low maintenance, while the chrome steel cage enhances durability. The bearing operates efficiently in temperatures ranging from -30°C to 120°C.

This model is interchangeable with SKF bearings, making it a practical choice for replacements. It’s well-suited for applications like small motors or pumps where reliable radial load support is needed.

Weighing just 0.043kg, it’s lightweight yet sturdy. Compliant with RoHS and REACH standards, it’s a safe and reliable option for various industrial uses.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number 61905/W64
  • Brand TFL
  • Interchangeable SKF
  • System of Measurement Metric
  • For Load Direction Radial
  • Construction Single Row
  • Bearing Type Ball
  • Seal Type Open
  • Tolerance Class ABEC 1 | ISO P0
  • Radial Clearance Trade No CN
  • Bore Dia 25 mm
  • Bore Dia Tolerance -0.008mm to 0
  • Outer Dia 42 mm
  • Outer Dia Tolerance -0.009mm to 0
  • Width 9 mm
  • Width Tolerance -0.12mm to 0
  • Ring Material Chrome Steel
  • Ball Material Chrome Steel
  • Cage Material Chrome Steel
  • Lubrication Soild Oil
  • ROHS Compliant
  • REACH Compliant
  • Temperature Range -30°to 120 °C
  • Dynamic Radial Load 1578 lbf
  • Static Radial Load 967 lbf
  • Max Speed 22000 rpm
  • Weight 0.043 kg
  • price（$） 15.525
Single Row Deep Groove Ball Bearings 61905/W64 dimension drawing
Download DWG Download PDF

Features

Why Choose 61905/W64 Bearing for Precision Tasks?

61905/W64 Bearing features a single row deep groove design, ideal for handling radial loads with precision.
Its chrome steel construction ensures durability and smooth operation in various applications.

The solid oil lubrication reduces maintenance needs while maintaining performance.
With a maximum speed of 22,000 rpm, it offers reliable efficiency for high-speed tasks.

61905/W64 Bearing operates within a temperature range of -30°C to 120°C, suitable for diverse environments.
Its ABEC 1 tolerance class provides consistent performance for precision requirements.

Application

Common Applications of 61905/W64 Bearing
61905/W64 Bearing is widely used in industrial equipment like small electric motors and pumps, where its compact size and radial load capacity are beneficial. The solid oil lubrication ensures smooth operation even in continuous-use scenarios.

In automotive applications, 61905/W64 Bearing fits well in components such as alternators and cooling fans, thanks to its reliable performance and metric dimensions. Its chrome steel construction also resists wear in high-temperature environments.

For automation systems, 61905/W64 Bearing works efficiently in robotic joints and conveyor rollers, providing stability under moderate loads. The open design allows for easy inspection and maintenance when needed.

In household appliances like washing machines, 61905/W64 Bearing offers quiet and durable operation. Its ABEC 1 tolerance ensures consistent performance without unnecessary complexity.
