Single Row Deep Groove Ball Bearings 607-2Z/C3MT37

Single Row Deep Groove Ball Bearings 607-2Z/C3MT37

The 607-2Z/C3MT37 is a compact single-row deep groove ball bearing, measuring 7mm by 19mm by 6mm. Made from durable chrome steel, it handles radial loads up to 447 lbf and spins smoothly at speeds up to 36,000 RPM.

Its shielded design keeps dirt out while maintaining smooth operation, and the C3 radial clearance allows for thermal expansion in various conditions. The bearing works well in temperatures from -30°C to 120°C.

This model is interchangeable with SKF bearings, making it a practical choice for replacements. Ideal for small motors, power tools, or appliances where reliable radial load support is needed.

Weighing just 7.8g, it’s lightweight yet sturdy for its size. Compliant with RoHS and REACH standards for safe use.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number 607-2Z/C3MT37
  • Brand TFL
  • Interchangeable SKF
  • System of Measurement Metric
  • For Load Direction Radial
  • Construction Single Row
  • Bearing Type Ball
  • Seal Type Shielded
  • Tolerance Class ABEC 1 | ISO P0
  • Radial Clearance Trade No C3
  • Bore Dia 7 mm
  • Bore Dia Tolerance -0.008mm to 0
  • Outer Dia 19 mm
  • Outer Dia Tolerance -0.008mm to 0
  • Width 6 mm
  • Width Tolerance -0.12mm to 0
  • Ring Material Chrome Steel
  • Ball Material Chrome Steel
  • Cage Material Chrome Steel
  • ROHS Compliant
  • REACH Compliant
  • Temperature Range -30°to 120 °C
  • Dynamic Radial Load 447 lbf
  • Static Radial Load 161 lbf
  • Max Speed 36000 rpm
  • Weight 7.8 g
Single Row Deep Groove Ball Bearings 607-2Z/C3MT37 dimension drawing
Download DWG Download PDF

Features

Performance Features of 607-2Z/C3MT37 Bearing

607-2Z/C3MT37 Bearing is designed with chrome steel rings and balls, offering strong resistance to radial loads.
Its dynamic radial load capacity reaches 447 lbf, ensuring reliable performance in various applications.

The shielded design of 607-2Z/C3MT37 Bearing protects against dust and contaminants, enhancing durability.
With a maximum speed of 36,000 rpm, it delivers smooth and efficient operation.

607-2Z/C3MT37 Bearing operates in temperatures from -30°C to 120°C, making it versatile for different environments.
Its C3 radial clearance provides optimal performance under varying load conditions.

The compact size of 7 mm×19 mm×6 mm makes 607-2Z/C3MT37 Bearing ideal for space-constrained applications.
Its lightweight design at just 7.8 g ensures easy handling without compromising strength.

Application

Common Applications of 607-2Z/C3MT37 Bearing
This compact bearing is great for small electric motors, often found in household appliances like fans or blenders. Its shielded design keeps dust out while maintaining smooth rotation.

Where Is 607-2Z/C3MT37 Bearing Used?
You’ll spot this bearing in power tools where its C3 clearance handles moderate radial loads effectively. The chrome steel construction offers decent durability for everyday DIY equipment.

Built for Versatility: 607-2Z/C3MT37 Bearing
It works well in printer mechanisms, supporting paper feed rollers with reliable performance. The metric sizing makes replacement straightforward across various European and Asian brands.

Light-Duty vs Heavy-Duty: Best Uses for 607-2Z/C3MT37 Bearing
While not for industrial crushers, 607-2Z/C3MT37 Bearing shines in light machinery like sewing machines. Its 36,000 rpm limit handles most small motor applications comfortably.
