Single Row Deep Groove Ball Bearings 6012-2RS1/C3

Single Row Deep Groove Ball Bearings 6012-2RS1/C3

The 6012-2RS1/C3 is a single-row deep groove ball bearing with a 60mm bore and 95mm outer diameter, crafted from sturdy chrome steel for lasting performance. It handles radial loads up to 6609 lbf and operates smoothly at speeds up to 7100 RPM.

Its sealed design keeps out dust and moisture, making it low-maintenance, while the C3 radial clearance allows for thermal expansion in various conditions. The bearing works reliably in temperatures from -30°C to 120°C.

This model is interchangeable with SKF bearings, offering a cost-effective alternative for replacements. Ideal for applications like electric motors or pumps where radial loads and moderate speeds are common.

Weighing 403g, it’s a robust yet manageable size for industrial use. Compliant with RoHS and REACH standards for safe and eco-friendly operation.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number 6012-2RS1/C3
  • Brand TFL
  • Interchangeable SKF
  • System of Measurement Metric
  • For Load Direction Radial
  • Construction Single Row
  • Bearing Type Ball
  • Seal Type Sealed
  • Tolerance Class ABEC 1 | ISO P0
  • Radial Clearance Trade No C3
  • Bore Dia 60 mm
  • Bore Dia Tolerance -0.015mm to 0
  • Outer Dia 95 mm
  • Outer Dia Tolerance -0.015mm to 0
  • Width 18 mm
  • Width Tolerance -0.150mm to 0
  • Ring Material Chrome Steel
  • Ball Material Chrome Steel
  • Cage Material Chrome Steel
  • ROHS Compliant
  • REACH Compliant
  • Temperature Range -30°to 120 °C
  • Dynamic Radial Load 6609 lbf
  • Static Radial Load 5216 lbf
  • Max Speed 7100 rpm
  • Weight 403 g
  • price（$） 14.463
Single Row Deep Groove Ball Bearings 6012-2RS1/C3 dimension drawing
Download DWG Download PDF

Features

Why Choose 6012-2RS1/C3 Bearing for Precision Tasks?

6012-2RS1/C3 Bearing features a sealed design, protecting against dust and moisture for consistent performance.
Its chrome steel construction ensures durability and resistance to wear in radial load applications.
With a dynamic radial load capacity of 6609 lbf, it handles demanding conditions reliably.
The bearing operates smoothly up to 7,100 rpm, making it suitable for high-speed applications.

Application

Industrial Uses of 6012-2RS1/C3 Bearing
This bearing is commonly used in industrial machinery like pumps and electric motors, where its sealed design helps keep out contaminants. The C3 radial clearance ensures smooth operation even under varying temperatures.

What Makes 6012-2RS1/C3 Bearing a Preferred Choice?
In automotive applications, 6012-2RS1/C3 Bearing works well in alternators and water pumps due to its reliable radial load capacity. The chrome steel construction offers good durability for everyday use.

Perfect Fit for Automation: 6012-2RS1/C3 Bearing
You’ll find this bearing in robotic arms and conveyor systems, where its sealed design reduces maintenance needs. The metric sizing makes it easy to integrate into various European and Asian equipment.

Medical vs Industrial: Where 6012-2RS1/C3 Bearing Excels
While not typically used in medical devices, 6012-2RS1/C3 Bearing shines in industrial settings like packaging machines. Its consistent performance and easy installation make it a practical choice.
