Single Row Deep Groove Ball Bearings 6001 TN9

Single Row Deep Groove Ball Bearings 6001 TN9

The 6001 TN9 is a compact single-row deep groove ball bearing, measuring 12mm by 28mm by 8mm, crafted from durable chrome steel. It handles radial loads up to 1147 lbf and spins smoothly at speeds up to 27,000 RPM.

Its open design and nylon cage make it lightweight (just 22g) and easy to maintain. The bearing performs reliably in temperatures ranging from -30°C to 120°C.

This model is interchangeable with SKF bearings, offering a practical replacement option. Ideal for small motors, fans, or appliances where smooth rotation is key.

Compliant with RoHS and REACH standards, it’s a safe and versatile choice for various applications. The ABEC 1 tolerance ensures consistent performance without overcomplicating installation.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number 6001 TN9
  • Brand TFL
  • Interchangeable SKF
  • System of Measurement Metric
  • For Load Direction Radial
  • Construction Single Row
  • Bearing Type Ball
  • Seal Type Open
  • Tolerance Class ABEC 1 | ISO P0
  • Radial Clearance Trade No CN
  • Bore Dia 12 mm
  • Bore Dia Tolerance -0.008mm to 0
  • Outer Dia 28 mm
  • Outer Dia Tolerance -0.009mm to 0
  • Width 8 mm
  • Width Tolerance -0.120mm to 0
  • Ring Material Chrome Steel
  • Ball Material Chrome Steel
  • Cage Material Nylon
  • ROHS Compliant
  • REACH Compliant
  • Temperature Range -30°to 120 °C
  • Dynamic Radial Load 1147 lbf
  • Static Radial Load 54 lbf
  • Max Speed 27000 rpm
  • Weight 22 g
Single Row Deep Groove Ball Bearings 6001 TN9 dimension drawing
Download DWG Download PDF

Features

Why Choose 6001 TN9 Bearing for Precision Tasks?

6001 TN9 Bearing features a single-row deep groove design, ideal for handling radial loads with precision.
Its chrome steel rings and balls ensure durability and smooth operation in various applications.

The nylon cage in 6001 TN9 Bearing helps reduce friction and noise, making it suitable for quiet environments.
With a dynamic radial load capacity of 1147 lbf, it performs reliably under stress.

6001 TN9 Bearing operates efficiently at speeds up to 27,000 rpm, balancing speed and longevity.
Its temperature range of -30°C to 120°C allows for use in diverse conditions.

The open design of 6001 TN9 Bearing simplifies maintenance, reducing downtime and costs.
Its lightweight construction at 22g ensures easy handling without compromising strength.

Application

Industrial Uses of 6001 TN9 Bearing
6001 TN9 Bearing is commonly used in small electric motors and pumps, where its compact size and radial load capacity make it a reliable choice. The open design allows for easy lubrication, extending service life in continuous operation.

What Makes 6001 TN9 Bearing a Preferred Choice?
In household appliances like washing machines, 6001 TN9 Bearing ensures smooth rotation with minimal noise. Its nylon cage reduces friction, making it energy-efficient for daily use.

Built for Heavy-Duty Use: 6001 TN9 Bearing
For conveyor systems in packaging lines, 6001 TN9 Bearing handles moderate radial loads with ease. The chrome steel construction offers durability in dusty or humid environments.

Automotive vs Aerospace: Applications of 6001 TN9 Bearing
In automotive alternators, 6001 TN9 Bearing provides stable performance under varying speeds. While not suited for extreme aerospace loads, it excels in light-duty mechanical applications.

Perfect Fit for Automation: 6001 TN9 Bearing
6001 TN9 Bearing works well in robotic arms, where precision and low maintenance are key. The ABEC 1 tolerance ensures consistent performance without unnecessary complexity.
