Single Row Deep Groove Ball Bearings 6001-2Z/C2

Single Row Deep Groove Ball Bearings 6001-2Z/C2

The 6001-2Z/C2 is a compact single-row deep groove ball bearing with a 12mm bore and 28mm outer diameter, crafted from durable chrome steel. It handles radial loads up to 1147 lbf and spins smoothly at speeds up to 27,000 RPM.

Its shielded design keeps out dust and debris, while the C2 radial clearance ensures reliable performance under varying temperatures (-30°C to 120°C). The chrome steel cage adds strength and longevity.

This bearing is interchangeable with SKF models, making it a practical choice for replacements. Ideal for small motors, power tools, or appliances where smooth rotation is key.

Weighing just 22g, it’s lightweight yet sturdy. Compliant with RoHS and REACH standards for safe use in various industries.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number 6001-2Z/C2
  • Brand TFL
  • Interchangeable SKF
  • System of Measurement Metric
  • For Load Direction Radial
  • Construction Single Row
  • Bearing Type Ball
  • Seal Type Shielded
  • Tolerance Class ABEC 1 | ISO P0
  • Radial Clearance Trade No C2
  • Bore Dia 12 mm
  • Bore Dia Tolerance -0.008mm to 0
  • Outer Dia 28 mm
  • Outer Dia Tolerance -0.009mm to 0
  • Width 8 mm
  • Width Tolerance -0.120mm to 0
  • Ring Material Chrome Steel
  • Ball Material Chrome Steel
  • Cage Material Chrome Steel
  • ROHS Compliant
  • REACH Compliant
  • Temperature Range -30°to 120 °C
  • Dynamic Radial Load 1147 lbf
  • Static Radial Load 54 lbf
  • Max Speed 27000 rpm
  • Weight 22 g
  • price（$） 2.808
Single Row Deep Groove Ball Bearings 6001-2Z/C2 dimension drawing
Download DWG Download PDF

Features

Performance Features of 6001-2Z/C2 Bearing

6001-2Z/C2 Bearing is designed with chrome steel rings and balls, offering strong resistance to radial loads.
Its dynamic radial load capacity reaches 1147 lbf, ensuring reliable performance in various applications.

The shielded design protects against dust and debris, enhancing durability.
With a maximum speed of 27,000 rpm, it balances efficiency and longevity.

6001-2Z/C2 Bearing operates smoothly in temperatures from -30°C to 120°C.
Its C2 radial clearance ensures optimal performance under different load conditions.

Application

Common Applications of 6001-2Z/C2 Bearing
6001-2Z/C2 Bearing is widely used in small electric motors, such as those found in household appliances and power tools. Its shielded design helps keep out dust and debris, extending the bearing’s lifespan.

In automotive applications, 6001-2Z/C2 Bearing can be found in components like alternators and water pumps. The C2 radial clearance ensures smooth operation even under varying temperature conditions.

For light industrial machinery, 6001-2Z/C2 Bearing offers reliable performance in conveyor systems and small gearboxes. The chrome steel construction provides good resistance to wear in moderate-load scenarios.

Where Is 6001-2Z/C2 Bearing Used?
You’ll often spot 6001-2Z/C2 Bearing in computer cooling fans and small office equipment. Its compact size and shielded design make it ideal for these space-constrained applications.

The bearing also works well in bicycle components like pedal assemblies. The ABEC 1 tolerance is sufficient for most cycling needs while keeping costs reasonable.

Built for Versatility: 6001-2Z/C2 Bearing
6001-2Z/C2 Bearing handles both radial and light axial loads effectively, making it suitable for various small machinery applications. The 28mm outer diameter fits standard housings nicely.

In food processing equipment, this bearing’s chrome steel construction meets basic hygiene requirements. The shielded design helps prevent contamination while allowing easy lubrication access.

Light-Duty vs Heavy-Duty: Best Uses for 6001-2Z/C2 Bearing
For light-duty applications like small fans or printers, 6001-2Z/C2 Bearing provides adequate performance at an economical price point. The 27,000 rpm maximum speed covers most common needs.

In more demanding situations like small power tools, the bearing’s C2 clearance helps accommodate slight misalignments. However, it’s not designed for continuous heavy loads or extreme conditions.
