Single Row Deep Groove Ball Bearings 6000-2Z/WT

Single Row Deep Groove Ball Bearings 6000-2Z/WT

The 6000-2Z/WT is a compact single row deep groove ball bearing, measuring 10mm in bore and 26mm in outer diameter, with a width of just 8mm. Made from durable chrome steel, it’s built to handle radial loads up to 1023 lbf.

Its shielded design keeps dirt out while maintaining smooth operation at speeds up to 31,000 RPM. The bearing works reliably in temperatures ranging from -30°C to 120°C.

This model is interchangeable with SKF bearings, making it a practical choice for replacements. Ideal for small electric motors or machinery where space is limited but performance is key.

Weighing only 19g, it’s lightweight yet sturdy. Compliant with RoHS and REACH standards for safe use.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number 6000-2Z/WT
  • Brand TFL
  • Interchangeable SKF
  • System of Measurement Metric
  • For Load Direction Radial
  • Construction Single Row
  • Bearing Type Ball
  • Seal Type Shielded
  • Tolerance Class ABEC 1 | ISO P0
  • Radial Clearance Trade No CN
  • Bore Dia 10 mm
  • Bore Dia Tolerance -0.008mm to 0
  • Outer Dia 26 mm
  • Outer Dia Tolerance -0.009mm to 0
  • Width 8 mm
  • Width Tolerance -0.120mm to 0
  • Ring Material Chrome Steel
  • Ball Material Chrome Steel
  • Cage Material Chrome Steel
  • ROHS Compliant
  • REACH Compliant
  • Temperature Range -30°to 120 °C
  • Dynamic Radial Load 1023 lbf
  • Static Radial Load 438 lbf
  • Max Speed 31000 rpm
  • Weight 19 g
Single Row Deep Groove Ball Bearings 6000-2Z/WT dimension drawing
Download DWG Download PDF

Features

Performance Features of 6000-2Z/WT Bearing

6000-2Z/WT Bearing is built with chrome steel rings and balls, offering reliable radial load support.
Its shielded design helps keep contaminants out, ensuring smoother operation over time.

The bearing can handle dynamic radial loads up to 1023 lbf, making it suitable for various applications.
With a maximum speed of 31,000 rpm, it delivers efficient performance in high-speed scenarios.

6000-2Z/WT Bearing operates in temperatures from -30°C to 120°C, adapting to different environments.
Its compact size (10 mm×26 mm×8 mm) makes it ideal for space-constrained installations.

The chrome steel cage maintains ball alignment, reducing friction and extending service life.
This design ensures consistent performance while minimising maintenance requirements.

Application

Common Applications of 6000-2Z/WT Bearing
6000-2Z/WT Bearing is widely used in industrial equipment like small motors and pumps, where its shielded design helps keep contaminants out. The chrome steel construction ensures durability in demanding environments.

In automotive applications, 6000-2Z/WT Bearing fits well in components such as alternators and cooling fans. Its compact size and radial load capacity make it a reliable choice for vehicle systems.

For consumer electronics, 6000-2Z/WT Bearing works smoothly in devices like printers and small fans. The ABEC 1 tolerance ensures consistent performance without unnecessary complexity.

Automation systems benefit from 6000-2Z/WT Bearing in robotic arms and conveyor belts, where its shielded seals reduce maintenance needs. The high-speed capability also supports efficient operation.

Medical devices like lab equipment often use 6000-2Z/WT Bearing for its reliable performance and clean operation. The temperature range suits both indoor and specialised environments.
