Single Row Angular Contact Ball Bearings (General) 7417 BAGAMC

Brand: TFL Bearing Interchangeable: SKF 7417 BAGAMC 85 mm × 210 mm × 52 mm Metric Open
Part number: 7417 BAGAMC
Single Row Angular Contact Ball Bearings (General) 7417 BAGAMC
In Stock
Price on request
Send your part number and quantity for a quote
Get a Quote WhatsApp
  • ISO 9001 quality system
  • RoHS & REACH compliant
  • Pre-shipment inspection
  • Lead time confirmed with your quote
Dimensions
Bore Dia85 mm
Bore Dia Tolerance-0.015mm to 0
Outer Dia210 mm
Outer Dia Tolerance-0.02mm to 0
Width52 mm
Width Tolerance-0.05mm to 0
External Diameter On Inner Ring (Large Side Face)127.631 mm
Internal Diameter On Outer Ring166.95 mm
Chamfer Dimension4 mm
Performance
Dynamic Radial Load42,750 lbf
Static Radial Load37,350 lbf
Temperature Range-30° to 110 °C
Max Speed4,000 rpm
Characteristics
System of MeasurementMetric
Bearing TypeBall
Contact Angle40°
For Load DirectionAngular Contact
ConstructionSingle Row
Seal TypeOpen
Distance Pressure Point (a)88 mm
LubricationLubricated
Tolerance ClassP6 (ABEC-3)
Weight9.6 kg
Material
Ring MaterialChrome Steel
Ball MaterialChrome Steel
Cage MaterialNylon
Compliance
ROHSCompliant
REACHCompliant
Dimension drawing · click to enlarge

Description

The 7417 BAGAMC is a single-row angular contact ball bearing with an 85mm bore and 210mm outer diameter, built from sturdy chrome steel. It handles radial loads up to 42750 lbf and operates smoothly at speeds up to 4000 RPM.

With a 40° contact angle, it efficiently manages combined radial and axial loads. The open design and nylon cage ensure durability while allowing easy lubrication.

This bearing is P6 tolerance class (ABEC-3) for precise performance. It works well in temperatures from -30°C to 110°C and is interchangeable with SKF models.

Ideal for machinery like pumps or gearboxes where angular contact is needed. Weighing 9.6kg, it’s robust yet manageable for industrial use. Compliant with RoHS and REACH standards.

Features

How Is 7417 BAGAMC Bearing Engineered for Reliability?

7417 BAGAMC Bearing features a 40° contact angle, optimised for handling combined radial and axial loads efficiently.
The chrome steel construction ensures durability, while the nylon cage reduces friction and noise during operation.

With a dynamic radial load capacity of 42,750 lbf, it performs reliably under heavy loads.
Its P6 tolerance class (ABEC-3) guarantees precision, making it suitable for high-accuracy applications.

The open design allows for easy lubrication, extending service life.
7417 BAGAMC Bearing operates smoothly within a temperature range of -30° to 110°C.

Application

Industrial Uses of 7417 BAGAMC Bearing
7417 BAGAMC Bearing is commonly used in heavy machinery like industrial pumps and compressors, where its angular contact design efficiently handles combined loads. The chrome steel construction ensures durability in demanding environments.

Where Is 7417 BAGAMC Bearing Used?
You’ll find 7417 BAGAMC Bearing in automotive applications such as wheel hubs and transmissions, thanks to its ability to manage high radial and axial loads. The nylon cage reduces friction, enhancing performance in high-speed scenarios.

Built for Heavy-Duty Use: 7417 BAGAMC Bearing
7417 BAGAMC Bearing excels in construction equipment, supporting components like crane swivels and excavator arms. Its P6 tolerance class guarantees precision even under heavy stress.

Automotive vs Aerospace: Applications of 7417 BAGAMC Bearing
In automotive systems, 7417 BAGAMC Bearing ensures smooth operation in gearboxes, while in aerospace, it’s trusted for auxiliary power units due to its reliability. The wide temperature range makes it versatile for various climates.

Perfect Fit for Automation: 7417 BAGAMC Bearing
7417 BAGAMC Bearing is ideal for robotic arms and CNC machines, where its 40° contact angle provides stability during precise movements. The lubricated design minimizes maintenance needs in continuous operation.
