Single Row Angular Contact Ball Bearings (General) 7319 BEP

Brand: TFL Bearing Interchangeable: SKF 7319 BEP 95 mm × 200 mm × 45 mm Metric Open
Part number: 7319 BEP
Single Row Angular Contact Ball Bearings (General) 7319 BEP
In Stock
US$153.98 / piece
Reference price · volume pricing on request
Get a Quote WhatsApp
  • ISO 9001 quality system
  • RoHS & REACH compliant
  • Pre-shipment inspection
  • Lead time confirmed with your quote
Dimensions
Bore Dia95 mm
Bore Dia Tolerance-0.015mm to 0
Outer Dia200 mm
Outer Dia Tolerance-0.02mm to 0
Width45 mm
Width Tolerance-0.05mm to 0
External Diameter On Inner Ring (Large Side Face)136.2 mm
External Diameter On Inner Ring (Small Side Face)114.92 mm
Internal Diameter On Outer Ring161.25 mm
Chamfer Dimension3 mm
Performance
Dynamic Radial Load37,800 lbf
Static Radial Load33,750 lbf
Temperature Range-30° to 110 °C
Max Speed3,800 rpm
Characteristics
System of MeasurementMetric
Bearing TypeBall
Contact Angle40°
For Load DirectionAngular Contact
ConstructionSingle Row
Seal TypeOpen
Distance Pressure Point (a)84 mm
LubricationLubricated
Tolerance ClassP6 (ABEC-3)
Weight6.05 kg
Material
Ring MaterialChrome Steel
Ball MaterialChrome Steel
Cage MaterialNylon
Compliance
ROHSCompliant
REACHCompliant
Dimension drawing · click to enlarge

Description

The 7319 BEP is a single-row angular contact ball bearing with a 95mm bore and 200mm outer diameter, crafted from sturdy chrome steel. It manages radial loads up to 37800 lbf and operates smoothly at speeds up to 3800 RPM.

Its 40° contact angle efficiently handles combined loads, while the nylon cage reduces friction and noise. The open design allows for easy lubrication and maintenance.

This bearing suits applications like pumps or gearboxes where angular contact is needed. It works in temperatures from -30°C to 110°C and meets P6 precision standards.

Weighing 6.05kg, it’s robust yet manageable for industrial use. Compliant with RoHS and REACH, it’s a reliable choice for replacements, interchangeable with SKF models.

Features

Performance Features of 7319 BEP Bearing

7319 BEP Bearing is designed with a 40° contact angle, ideal for handling combined radial and axial loads.
Its chrome steel construction ensures durability and resistance to wear in demanding applications.

The nylon cage in 7319 BEP Bearing reduces friction and noise, making it suitable for precision tasks.
With a dynamic radial load capacity of 37,800 lbf, it performs reliably under heavy loads.

7319 BEP Bearing operates smoothly at speeds up to 3,800 rpm, balancing efficiency and longevity.
Its open design allows for easy lubrication, ensuring consistent performance over time.

The bearing’s P6 tolerance class guarantees high precision, meeting strict industry standards.
Its temperature range of -30° to 110°C makes it versatile for various operating conditions.

Application

Industrial Uses of 7319 BEP Bearing
7319 BEP Bearing is commonly used in machine tools, where its angular contact design efficiently handles combined radial and axial loads. The nylon cage reduces friction, making it suitable for high-speed operations.

Where Is 7319 BEP Bearing Used?
In automotive applications, 7319 BEP Bearing supports wheel hubs and transmissions, thanks to its robust chrome steel construction. The 40° contact angle ensures stability under varying load conditions.

Perfect Fit for Automation: 7319 BEP Bearing
7319 BEP Bearing works well in robotic arms, providing smooth movement and precise positioning. Its open seal type allows for easy lubrication, extending service life in demanding environments.

Medical vs Industrial: Where 7319 BEP Bearing Excels
7319 BEP Bearing is ideal for industrial pumps, offering reliable performance under heavy loads. In medical devices, its precision and low noise make it a good fit for diagnostic equipment.

Light-Duty vs Heavy-Duty: Best Uses for 7319 BEP Bearing
7319 BEP Bearing handles light-duty tasks in household appliances like washing machines. For heavy-duty use, it excels in construction machinery, where durability is key.
