Self Aligning Ball Bearings 2213 ETN9

Self Aligning Ball Bearings 2213 ETN9

The 2213 ETN9 is a self-aligning ball bearing with a 65mm bore and 120mm outer diameter, crafted from sturdy chrome steel. It manages radial loads up to 12870 lbf and operates smoothly at speeds reaching 7000 RPM.

Its double-row design and open seal allow for easy lubrication and alignment adjustments, while the nylon cage reduces friction. The bearing performs reliably in temperatures from -30°C to 110°C.

This model is interchangeable with SKF bearings, making it a practical choice for replacements. Suitable for applications like conveyor systems or agricultural machinery where misalignment might occur.

Weighing 1.45kg, it offers a balance of strength and durability. Compliant with RoHS and REACH standards for safe use.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number 2213 ETN9
  • Brand TFL & OEM
  • Interchangeable SKF
  • Bore Dia 65 mm
  • Bore Dia Tolerance -0.015mm to 0
  • Outer Dia 120 mm
  • Outer Dia Tolerance -0.015mm to 0
  • Width 31 mm
  • Width Tolerance -0.15mm to 0
  • External Diameter On Inner Ring 80.68 mm
  • Internal Diameter On Outer Ring 105.5 mm
  • Chamfer Dimension 1.5 mm
  • System of Measurement Metric
  • Bearing Type Ball
  • For Load Direction Radial
  • Construction Double Row
  • Seal Type Open
  • Ring Material Chrome Steel
  • Ball Material Chrome Steel
  • Cage Material Nylon
  • Dynamic Radial Load 12870 lbf
  • Static Radial Load 4500 lbf
  • Lubrication Lubricated
  • Temperature Range -30° to 110 °C
  • RoHS Compliant
  • REACH Compliant
  • Max Speed 7000 rpm
  • Weight 1.45 kg
  • Price（$） 53.67
Self Aligning Ball Bearings 2213 ETN9 dimension drawing
Download DWG Download PDF

Features

Why Choose 2213 ETN9 Bearing for Precision Tasks?

2213 ETN9 Bearing features a double-row design with chrome steel rings and balls, ensuring high radial load capacity.
Its dynamic radial load reaches 12870 lbf, making it suitable for demanding industrial applications.

The nylon cage in 2213 ETN9 Bearing reduces friction and noise, enhancing smooth operation.
With a maximum speed of 7,000 rpm, it delivers reliable performance in various conditions.

2213 ETN9 Bearing operates efficiently within a temperature range of -30° to 110°C.
Its open design simplifies maintenance while maintaining durability.

Application

Industrial Uses of 2213 ETN9 Bearing
2213 ETN9 Bearing is commonly used in industrial machinery like conveyor systems and fans, where its self-aligning feature helps compensate for minor misalignments. The double-row design provides reliable radial load support in demanding environments.

Where Is 2213 ETN9 Bearing Used?
You’ll often find 2213 ETN9 Bearing in automotive applications such as gearboxes and wheel hubs, where its durability and smooth operation are key. The metric sizing ensures compatibility with a variety of vehicle designs.

Perfect Fit for Automation: 2213 ETN9 Bearing
In robotic arms and automated production lines, 2213 ETN9 Bearing’s nylon cage reduces friction and noise, making it ideal for precision movements. Its open design allows for easy lubrication, extending service life.

Medical vs Industrial: Where 2213 ETN9 Bearing Excels
While 2213 ETN9 Bearing performs well in industrial settings, it’s also suited for medical devices like imaging equipment, where consistent rotation is essential. The chrome steel construction ensures reliability in both fields.

Consumer Electronics and 2213 ETN9 Bearing
For household appliances like washing machines and fans, 2213 ETN9 Bearing offers quiet and efficient operation. Its self-aligning capability helps maintain performance even with slight installation errors.
