Self Aligning Ball Bearings 2210-2RSTN

Self Aligning Ball Bearings 2210-2RSTN

The 2210-2RSTN is a self-aligning ball bearing with a 50mm bore and 90mm outer diameter, crafted from sturdy chrome steel. Its double-row design and sealed construction help it handle radial loads up to 5152 lbf while running smoothly at 4800 RPM.

The nylon cage reduces friction and noise, making it a quiet performer. Pre-lubricated and ready to use, it operates well in temperatures from -30°C to 110°C.

This bearing is interchangeable with SKF models, offering a reliable alternative for replacements. Its self-aligning feature compensates for minor misalignments, ideal for applications like conveyor systems or agricultural machinery.

Weighing 0.57kg, it’s a robust yet manageable size. Compliant with RoHS and REACH standards for safe and eco-friendly use.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number 2210-2RSTN
  • Brand TFL & OEM
  • Interchangeable SKF
  • Bore Dia 50 mm
  • Bore Dia Tolerance -0.012mm to 0
  • Outer Dia 90 mm
  • Outer Dia Tolerance -0.015mm to 0
  • Width 23 mm
  • Width Tolerance -0.12mm to 0
  • External Diameter On Inner Ring 57.7 mm
  • Internal Diameter On Outer Ring 79.4 mm
  • Chamfer Dimension 1.1 mm
  • System of Measurement Metric
  • Bearing Type Ball
  • Bore Type Cylindrical
  • For Load Direction Radial
  • Construction Double Row
  • Seal Type Sealed
  • Ring Material Chrome Steel
  • Ball Material Chrome Steel
  • Cage Material Nylon
  • Dynamic Radial Load 5152 lbf
  • Static Radial Load 1834 lbf
  • Lubrication Lubricated
  • Temperature Range -30° to 110 °C
  • Radial Clearance CN
  • RoHS Compliant
  • REACH Compliant
  • Max Speed 4800 rpm
  • Weight 0.57 kg
  • Price（$） 118.09
Self Aligning Ball Bearings 2210-2RSTN dimension drawing
Download DWG Download PDF

Features

How Does 2210-2RSTN Bearing Ensure Smooth Operation?

2210-2RSTN Bearing features a double-row design with chrome steel rings and balls, offering excellent radial load capacity.
Its dynamic radial load rating of 5152 lbf ensures reliable performance in various applications.

The sealed construction and nylon cage help maintain smooth operation by keeping contaminants out.
With a maximum speed of 4,800 rpm, it balances efficiency and durability.

2210-2RSTN Bearing’s self-aligning capability compensates for minor misalignments, reducing wear.
Its temperature range of -30° to 110°C makes it suitable for diverse operating conditions.

Application

Ideal for Precision: 2210-2RSTN Bearing
2210-2RSTN Bearing is commonly used in industrial machinery, especially where misalignment compensation is needed, like in conveyor systems and fans. Its double-row design helps maintain smooth operation even under radial loads.

In automotive applications, 2210-2RSTN Bearing fits well in components like wheel hubs and transmissions, thanks to its sealed construction that keeps contaminants out. The nylon cage reduces friction, enhancing longevity.

For medical devices such as diagnostic equipment, 2210-2RSTN Bearing offers reliable performance due to its chrome steel rings. The lubricated design ensures quiet operation, which is essential in sensitive environments.

Automation systems benefit from 2210-2RSTN Bearing in robotic arms and assembly lines, where its self-aligning feature reduces wear. The metric sizing makes it easy to integrate into various European and Asian machinery.
