Self Aligning Ball Bearings 2207-2RSTN

Brand: TFL Bearing Interchangeable: SKF 2207-2RSTN 35 mm × 72 mm × 23 mm Metric Sealed
Part number: 2207-2RSTN
Self Aligning Ball Bearings 2207-2RSTN
In Stock
US$81.27 / piece
Reference price · volume pricing on request
Get a Quote WhatsApp
  • ISO 9001 quality system
  • RoHS & REACH compliant
  • Pre-shipment inspection
  • Lead time confirmed with your quote
Dimensions
Bore Dia35 mm
Bore Dia Tolerance-0.012mm to 0
Outer Dia72 mm
Outer Dia Tolerance-0.013mm to 0
Width23 mm
Width Tolerance-0.12mm to 0
External Diameter On Inner Ring42.7 mm
Internal Diameter On Outer Ring62.69 mm
Chamfer Dimension1.1 mm
Performance
Dynamic Radial Load4,275 lbf
Static Radial Load1,350 lbf
Temperature Range-30° to 110 °C
Max Speed6,300 rpm
Characteristics
System of MeasurementMetric
Bearing TypeBall
Bore TypeCylindrical
For Load DirectionRadial
ConstructionDouble Row
Seal TypeSealed
LubricationLubricated
Radial ClearanceCN
Weight0.41 kg
Material
Ring MaterialChrome Steel
Ball MaterialChrome Steel
Cage MaterialNylon
Compliance
RoHSCompliant
REACHCompliant
Dimension drawing · click to enlarge

Description

The 2207-2RSTN is a self-aligning ball bearing with a 35mm bore and 72mm outer diameter, crafted from sturdy chrome steel. It manages radial loads up to 4275 lbf and operates smoothly at speeds up to 6300 RPM.

Its double-row design and sealed construction help maintain alignment and keep dirt out, while the nylon cage reduces friction. The bearing comes pre-lubricated for easy installation.

Suitable for temperatures from -30°C to 110°C, it’s a versatile choice for machinery with slight misalignments. Ideal for conveyor systems or agricultural equipment where reliability is key.

Weighing 0.41kg, it’s robust yet manageable for its size. Compliant with RoHS and REACH standards, it’s a safe and dependable option for various industrial applications.

Features

Why Choose 2207-2RSTN Bearing for Precision Tasks?

2207-2RSTN Bearing features a double-row design with chrome steel rings and balls, ensuring precise radial load handling.
Its dynamic radial load capacity of 4275 lbf makes it suitable for demanding applications.

The sealed construction and nylon cage reduce friction and protect against contaminants.
This design ensures smooth operation and extends the bearing’s service life.

With a maximum speed of 6,300 rpm, 2207-2RSTN Bearing balances performance and durability.
Its temperature range of -30° to 110°C allows reliable use in various environments.

Application

Industrial Uses of 2207-2RSTN Bearing
2207-2RSTN Bearing is commonly used in conveyor systems, where its self-aligning feature compensates for minor misalignments. The sealed design keeps contaminants out, ensuring long service life in dusty environments.

Where Is 2207-2RSTN Bearing Used?
You’ll find 2207-2RSTN Bearing in agricultural machinery, such as harvesters, where it handles radial loads smoothly. Its nylon cage reduces friction, making it efficient for moderate-speed applications.

Built for Heavy-Duty Use: 2207-2RSTN Bearing
2207-2RSTN Bearing works well in industrial fans, supporting shafts that experience slight misalignment. The chrome steel construction provides durability, even in high-temperature conditions.

Automotive vs Aerospace: Applications of 2207-2RSTN Bearing
In automotive applications, 2207-2RSTN Bearing fits well in auxiliary units like water pumps. For aerospace, its reliability makes it suitable for non-critical rotating components.

Practical Applications of 2207-2RSTN Bearing
2207-2RSTN Bearing is a good choice for textile machinery, where it manages radial loads with ease. The lubricated design ensures smooth operation without frequent maintenance.
