Self Aligning Ball Bearings 2211KJ

Brand: TFL Bearing Interchangeable: SKF 2211KJ 55 mm × 100 mm × 25 mm Metric Sealed
Part number: 2211KJ
Self Aligning Ball Bearings 2211KJ
In Stock
US$68.28 / piece
Reference price · volume pricing on request
Get a Quote WhatsApp
  • ISO 9001 quality system
  • RoHS & REACH compliant
  • Pre-shipment inspection
  • Lead time confirmed with your quote
Dimensions
Bore Dia55 mm
Bore Dia Tolerance-0.015mm to 0
Outer Dia100 mm
Outer Dia Tolerance-0.015mm to 0
Width25 mm
Width Tolerance-0.15mm to 0
External Diameter On Inner Ring65.9 mm
Internal Diameter On Outer Ring88.5 mm
Chamfer Dimension1.5 mm
Performance
Dynamic Radial Load6,210 lbf
Static Radial Load2,385 lbf
Temperature Range-30° to 110 °C
Max Speed4,300 rpm
Characteristics
System of MeasurementMetric
Bearing TypeBall
Bore TypeTaper 1:12
For Load DirectionRadial
ConstructionDouble Row
Seal TypeSealed
LubricationLubricated
Radial ClearanceCN
Weight0.79 kg
Material
Ring MaterialChrome Steel
Ball MaterialChrome Steel
Cage MaterialSteel
Compliance
RoHSCompliant
REACHCompliant
Dimension drawing · click to enlarge

Description

The 2211KJ is a self-aligning ball bearing with a 55mm tapered bore and 100mm outer diameter, crafted from sturdy chrome steel. It manages radial loads up to 6210 lbf and runs smoothly at speeds up to 4300 RPM.

Its double-row design and sealed construction help it handle misalignment while keeping dirt out, making maintenance easier. The steel cage adds durability, and it comes pre-lubricated for immediate use.

This bearing suits environments with slight shaft misalignment, such as conveyor systems or agricultural machinery. It operates reliably in temperatures from -30°C to 110°C.

Weighing 0.79kg, it’s a robust choice for industrial applications. Compliant with RoHS and REACH standards, it’s also interchangeable with SKF bearings for easy replacement.

Features

How Is 2211KJ Bearing Engineered for Reliability?

2211KJ Bearing features a double-row design with chrome steel rings and balls, ensuring strong radial load capacity.
Its dynamic radial load rating of 6210 lbf makes it suitable for demanding applications.
The sealed construction keeps contaminants out, enhancing durability in harsh environments.
With a maximum speed of 4,300 rpm, it offers a balance of performance and longevity.

Application

Key Fields for 2211KJ Bearing
2211KJ Bearing is commonly used in industrial machinery like conveyors and mixers, where its self-aligning feature helps compensate for shaft misalignment. The sealed design keeps contaminants out, extending service life in dusty environments.

In automotive applications, 2211KJ Bearing fits well in wheel hubs and transmissions, thanks to its double-row construction handling radial loads efficiently. The taper bore ensures a secure fit on shafts, reducing slippage during operation.

For automation systems, 2211KJ Bearing works smoothly in robotic arms and assembly lines, where precision and reliability are key. The lubricated design minimises friction, ensuring consistent performance over time.

In household appliances like washing machines, 2211KJ Bearing’s durability and sealed construction make it ideal for high-moisture environments. Its chrome steel balls provide quiet operation, enhancing user comfort.

Medical imaging devices benefit from 2211KJ Bearing’s stable performance and low maintenance needs. The steel cage and sealed design ensure reliability in critical healthcare applications.
