Self Aligning Ball Bearings 2207 E-2RS1KTN9

Self Aligning Ball Bearings 2207 E-2RS1KTN9

The 2207 E-2RS1KTN9 is a self-aligning ball bearing with a 35mm bore and 72mm outer diameter, designed for radial loads. Its compact 23mm width makes it suitable for tight spaces, while the double-row construction ensures stability.

Made from chrome steel with a nylon cage, it handles dynamic radial loads up to 4275 lbf and spins smoothly at 6300 RPM. The sealed design keeps lubrication in and contaminants out, reducing maintenance needs.

This bearing operates well in temperatures from -30°C to 110°C and is interchangeable with SKF models. Ideal for applications like conveyor systems or agricultural machinery where misalignment might occur.

Weighing 0.41kg, it’s a durable yet lightweight option. Compliant with RoHS and REACH standards, it’s a reliable choice for various industrial uses.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number 2207 E-2RS1KTN9
  • Brand TFL & OEM
  • Interchangeable SKF
  • Bore Dia 35 mm
  • Bore Dia Tolerance -0.012mm to 0
  • Outer Dia 72 mm
  • Outer Dia Tolerance -0.013mm to 0
  • Width 23 mm
  • Width Tolerance -0.12mm to 0
  • External Diameter On Inner Ring 42.7 mm
  • Internal Diameter On Outer Ring 62.69 mm
  • Chamfer Dimension 1.1 mm
  • System of Measurement Metric
  • Bearing Type Ball
  • For Load Direction Radial
  • Construction Double Row
  • Seal Type Sealed
  • Ring Material Chrome Steel
  • Ball Material Chrome Steel
  • Cage Material Nylon
  • Dynamic Radial Load 4275 lbf
  • Static Radial Load 1350 lbf
  • Lubrication Lubricated
  • Temperature Range -30° to 110 °C
  • RoHS Compliant
  • REACH Compliant
  • Max Speed 6300 rpm
  • Weight 0.41 kg
  • Price（$） 46.49
Self Aligning Ball Bearings 2207 E-2RS1KTN9 dimension drawing
Download DWG Download PDF

Features

How Does 2207 E-2RS1KTN9 Bearing Reduce Friction?

2207 E-2RS1KTN9 Bearing features a double-row design with chrome steel rings and balls, ensuring smooth radial load distribution.
The nylon cage minimises friction, enhancing efficiency and reducing wear during operation.
With a dynamic radial load capacity of 4275 lbf, it performs reliably in various applications.
Its sealed design keeps lubrication intact, maintaining performance even in dusty environments.

Application

Common Applications of 2207 E-2RS1KTN9 Bearing
In industrial settings, 2207 E-2RS1KTN9 Bearing is often used in conveyor systems and fans, where its self-aligning feature compensates for minor misalignments. The sealed design keeps contaminants out, extending its service life in dusty environments.

How Does 2207 E-2RS1KTN9 Bearing Improve Performance?
For automotive applications like electric motors, 2207 E-2RS1KTN9 Bearing reduces friction and wear, ensuring smooth operation. Its nylon cage and chrome steel construction provide a good balance of strength and flexibility.

Built for Heavy-Duty Use: 2207 E-2RS1KTN9 Bearing
In automation and robotics, 2207 E-2RS1KTN9 Bearing handles radial loads efficiently, making it suitable for robotic arms and assembly lines. The double-row design enhances stability under varying load conditions.

Medical vs Industrial: Where 2207 E-2RS1KTN9 Bearing Excels
While 2207 E-2RS1KTN9 Bearing performs well in industrial machinery, it’s also reliable in medical devices like lab equipment, where precision and cleanliness are key. The lubricated seals ensure consistent performance without frequent maintenance.

Perfect Fit for Automation: 2207 E-2RS1KTN9 Bearing
In 3D printers and automated production lines, 2207 E-2RS1KTN9 Bearing offers quiet and efficient operation. Its metric dimensions make it easy to integrate into various European and Asian machine designs.
