Self Aligning Ball Bearings 1325

Self Aligning Ball Bearings 1325

The 1325 is a self-aligning ball bearing with a 125mm bore and 175mm outer diameter, crafted from sturdy 52100 chrome steel. It manages radial loads up to 10720 lbf and operates at speeds up to 1900 RPM.
Its open design simplifies lubrication, while the chrome steel cage enhances durability. The bearing performs reliably in temperatures ranging from -30°C to 110°C.
This model is interchangeable with SKF bearings, offering a practical replacement option. Suitable for heavy-duty applications like conveyor systems or agricultural machinery where misalignment might occur.
Weighing 3.97kg, it’s built to handle tough conditions while complying with RoHS and REACH standards.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number 1325
  • Brand TFL & OEM
  • Interchangeable SKF
  • Bore Dia 125 mm
  • Bore Dia Tolerance -0.025mm to 0
  • Outer Dia 175 mm
  • Outer Dia Tolerance -0.025mm to 0
  • Width 53 mm
  • Width Tolerance +0.025mm to -0.4mm
  • System of Measurement Metric
  • Bearing Type Ball
  • Seal Type Open
  • Ring Material 52100 Chrome Steel
  • Ball Material 52100 Chrome Steel
  • Cage Material Chrome Steel
  • Dynamic Radial Load 10720 lbf
  • Static Radial Load 93740 lbf
  • Lubrication Required
  • Temperature Range -30° to 110 °C
  • RoHS Compliant
  • REACH Compliant
  • Max Speed 1900 rpm
  • Weight 3.97 kg
Self Aligning Ball Bearings 1325 dimension drawing
Download DWG Download PDF

Features

Performance Features of 1325 Bearing

1325 Bearing is crafted from 52100 chrome steel, offering robust resistance to wear and high radial loads.
Its dynamic radial load capacity of 10720 lbf ensures reliable performance in heavy-duty applications.
The open design allows for easy lubrication, maintaining smooth operation over time.
With a maximum speed of 1,900 rpm, it balances durability and efficiency in various conditions.

Application

Industrial Uses of 1325 Bearing
1325 Bearing is commonly used in heavy machinery like conveyors and mixers, where its self-aligning feature compensates for minor misalignments. The chrome steel construction ensures durability in demanding industrial environments.

What Makes 1325 Bearing a Preferred Choice?
With its open design, 1325 Bearing allows for easy lubrication, making it ideal for applications requiring frequent maintenance. Its high static radial load capacity also suits equipment like crushers and pulverisers.

Built for Heavy-Duty Use: 1325 Bearing
1325 Bearing excels in construction equipment, handling uneven loads with ease. The wide temperature range ensures reliable performance in both hot and cold working conditions.

Automotive vs Aerospace: Applications of 1325 Bearing
In automotive systems, 1325 Bearing supports components like heavy-duty axles and gearboxes. For aerospace, its precision and load capacity make it suitable for auxiliary machinery.

Perfect Fit for Automation: 1325 Bearing
1325 Bearing is often found in robotic arms and assembly lines, where smooth rotation is essential. The metric sizing ensures compatibility with a variety of automated systems.
