Self Aligning Ball Bearings 1317JC3

Self Aligning Ball Bearings 1317JC3

The 1317JC3 is a self-aligning ball bearing with an 85mm bore and 180mm outer diameter, designed for radial loads. Its double-row construction and chrome steel components ensure durability under heavy use, handling up to 21938 lbf of dynamic load.

With a maximum speed of 4800 RPM, it operates smoothly in temperatures from -30°C to 110°C. The open seal design allows for easy lubrication, while the steel cage provides stability.

This bearing is interchangeable with SKF models, making it a practical choice for replacements. Ideal for machinery requiring alignment flexibility, such as conveyor systems or agricultural equipment.

Weighing 5kg, it’s robust yet manageable for its size. Compliant with RoHS and REACH standards, it’s safe for various industrial applications.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number 1317JC3
  • Brand TFL & OEM
  • Interchangeable SKF
  • Bore Dia 85 mm
  • Bore Dia Tolerance -0.02mm to 0
  • Outer Dia 180 mm
  • Outer Dia Tolerance -0.025mm to 0
  • Width 41 mm
  • Width Tolerance -0.2mm to 0
  • External Diameter On Inner Ring 117.6 mm
  • Internal Diameter On Outer Ring 152.8 mm
  • Chamfer Dimension 3 mm
  • System of Measurement Metric
  • Bearing Type Ball
  • Bore Type Cylindrical
  • For Load Direction Radial
  • Construction Double Row
  • Seal Type Open
  • Ring Material Chrome Steel
  • Ball Material Chrome Steel
  • Cage Material Steel
  • Dynamic Radial Load 21938 lbf
  • Static Radial Load 8550 lbf
  • Lubrication Lubricated
  • Temperature Range -30° to 110 °C
  • Radial Clearance C3
  • RoHS Compliant
  • REACH Compliant
  • Max Speed 4800 rpm
  • Weight 5 kg
Self Aligning Ball Bearings 1317JC3 dimension drawing
Download DWG Download PDF

Features

Performance Features of 1317JC3 Bearing

1317JC3 Bearing is crafted with chrome steel rings and balls, offering robust resistance to radial loads.
Its dynamic radial load capacity reaches 21938 lbf, ensuring dependable performance in various applications.

The double-row construction enhances load distribution, reducing stress on individual components.
With a maximum speed of 4,800 rpm, it balances efficiency and durability for long-term use.

1317JC3 Bearing operates smoothly within a temperature range of -30° to 110°C.
Its C3 radial clearance allows for slight misalignment, making it versatile in different setups.

Application

Industrial Uses of 1317JC3 Bearing
1317JC3 Bearing is commonly used in heavy machinery like conveyor systems and industrial fans, where its double-row design helps manage misalignment issues. The open seal type allows for easy lubrication, extending its service life in demanding environments.

What Makes 1317JC3 Bearing a Preferred Choice?
With its chrome steel construction, 1317JC3 Bearing offers reliable performance in radial load applications such as gearboxes and electric motors. The C3 radial clearance ensures smooth operation even under varying thermal conditions.

Built for Heavy-Duty Use: 1317JC3 Bearing
1317JC3 Bearing excels in construction equipment, where its robust design handles high radial loads effortlessly. The steel cage provides added durability, making it suitable for long-term use in harsh conditions.

Automotive vs Aerospace: Applications of 1317JC3 Bearing
In automotive applications, 1317JC3 Bearing supports components like wheel hubs and transmissions, thanks to its high dynamic load capacity. For aerospace, its precision engineering ensures reliability in auxiliary systems.

Perfect Fit for Automation: 1317JC3 Bearing
1317JC3 Bearing is ideal for robotic arms and automated production lines, where its self-aligning feature compensates for minor misalignments. The metric sizing ensures compatibility with a wide range of machinery.
