Inch Size Miniature Flanged Ball Bearings SFR3

Inch Size Miniature Flanged Ball Bearings SFR3

The SFR3 is a compact, flanged ball bearing measuring 0.1875″ in bore diameter and 0.5″ in outer diameter, crafted entirely from stainless steel for durability. It supports radial loads up to 224 lbf and can spin at speeds up to 38,700 RPM.

Its open design simplifies lubrication, while the stainless steel cage ensures smooth operation. The flange provides secure mounting, making it less likely to shift during use.

With a radial clearance of 0.00008″ to 0.0005″, it offers precise movement for small applications. The bearing performs well in temperatures ranging from -86°F to 230°F.

Ideal for miniature devices like small motors or precision instruments where space is limited. Weighing just 2.5g, it’s lightweight yet sturdy. Compliant with RoHS and REACH standards for safe use.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number SFR3
  • Brand TFL
  • System of Measurement Inch
  • Bearing Type Ball
  • For Load Direction Radial
  • Construction Single Row
  • Inner Ring Type Standard
  • Seal Type Open
  • Tolerance Class ABEC1
  • Radial Clearance Trade No MC3
  • Radial Clearance 0.00008" to 0.0005"
  • Ball Qty 7
  • Bore Dia 0.1875"
  • Bore Dia Tolerance -0.0003" to 0"
  • Outer Dia 0.5"
  • Outer Dia Tolerance -0.0003" to 0"
  • Width 0.156"
  • Width Tolerance -0.005" to 0"
  • Flange Outer Dia 0.565"
  • Flange Thickness 0.042"
  • Ball Dia 0.09370"
  • Ring Material Stainless Steel
  • Ball Material Stainless Steel
  • Cage Material Stainless Steel
  • Dynamic Radial Load 224 lbf
  • Static Radial Load 79 lbf
  • Max Speed 38700 rpm
  • Temperature Range -86 to 230 °F
  • Lubrication Required
  • RoHS Compliant
  • REACH Compliant
  • Weight 2.5 g
  • Price（$） 1.3122
Inch Size Miniature Flanged Ball Bearings SFR3 dimension drawing
Download DWG Download PDF

Features

How Does SFR3 Bearing Reduce Friction?

SFR3 Bearing uses stainless steel balls and rings, which help minimise friction during operation.

Its precision design with seven balls ensures smooth rotation, even at high speeds up to 38,700 rpm.

The open seal type allows for easy lubrication, further reducing friction and wear.

With a radial clearance of 0.00008″ to 0.0005″, it maintains consistent performance in various applications.

Application

Common Applications of SFR3 Bearing
SFR3 Bearing works well in small machinery, like dental drills or camera mechanisms, where its compact size and stainless steel build handle light radial loads smoothly. The open design simplifies lubrication, keeping maintenance straightforward.

Industrial Uses of SFR3 Bearing
In automation systems, SFR3 Bearing fits neatly into robotic arms or conveyor guides, thanks to its flanged outer ring for secure mounting. Its ABEC1 tolerance ensures reliable performance without overcomplicating assembly.

Where Is SFR3 Bearing Used?
You’ll often spot SFR3 Bearing in hobbyist projects, such as RC cars or 3D printers, where precision and corrosion resistance matter. The lightweight design (just 2.5g) won’t bog down delicate movements.

Built for Versatility: SFR3 Bearing
From lab equipment to small fans, SFR3 Bearing’s wide temperature range (-86 to 230°F) handles varied environments. The stainless steel balls and rings resist wear, even with frequent use.

Light-Duty vs Heavy-Duty: Best Uses for SFR3 Bearing
While SFR3 Bearing excels in low-force applications like optical devices, it’s not suited for heavy machinery. Its 224 lbf dynamic load rating makes it ideal for precision over brute strength.
