Single Row Deep Groove Ball Bearings 6310 M/C3VL0241

Single Row Deep Groove Ball Bearings 6310 M/C3VL0241

The 6310 M/C3VL0241 is a single-row deep groove ball bearing with a 50mm bore and 110mm outer diameter, crafted from sturdy chrome steel. It manages radial loads up to 13938 lbf and operates smoothly at speeds reaching 6000 RPM.

Its open design allows for easy lubrication, while the machined metal cage ensures durability. The bearing performs reliably in temperatures ranging from -30°C to 120°C.

With a C3 radial clearance, it offers flexibility for various applications. This model is interchangeable with SKF bearings, making it a practical choice for replacements.

Ideal for machinery like pumps or electric motors where radial loads are common. Weighing 1050g, it’s robust yet manageable for its size. Compliant with RoHS and REACH standards for safe use.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number 6310 M/C3VL0241
  • Brand TFL
  • Interchangeable SKF
  • System of Measurement Metric
  • For Load Direction Radial
  • Construction Single Row
  • Bearing Type Ball
  • Seal Type Open
  • Tolerance Class ABEC 1 | ISO P0
  • Radial Clearance Trade No C3
  • Bore Dia 50 mm
  • Bore Dia Tolerance -0.012mm to 0
  • Outer Dia 110 mm
  • Outer Dia Tolerance -0.015mm to 0
  • Width 27 mm
  • Width Tolerance -0.120mm to 0
  • Ring Material Chrome Steel
  • Ball Material Chrome Steel
  • Cage Material Machined metal
  • ROHS Compliant
  • REACH Compliant
  • Temperature Range -30°to 120 °C
  • Dynamic Radial Load 13938 lbf
  • Static Radial Load 861 lbf
  • Max Speed 6000 rpm
  • Weight 1050 g
  • price（$） 156.258
Single Row Deep Groove Ball Bearings 6310 M/C3VL0241 dimension drawing
Download DWG Download PDF

Features

Performance Features of 6310 M/C3VL0241 Bearing

6310 M/C3VL0241 Bearing is built with chrome steel rings and balls, ensuring durability under radial loads.
Its dynamic radial load capacity of 13938 lbf makes it suitable for heavy-duty applications.

The machined metal cage maintains ball alignment, reducing friction and wear.
With a maximum speed of 6,000 rpm, it offers reliable performance in various conditions.

6310 M/C3VL0241 Bearing operates efficiently within a temperature range of -30° to 120°C.
Its open design allows for easy lubrication, enhancing its service life.

The C3 radial clearance provides flexibility in different operational environments.
This bearing is compatible with SKF models, ensuring easy replacement and interchangeability.

Application

Industrial Uses of 6310 M/C3VL0241 Bearing
This bearing is commonly used in industrial machinery like pumps and electric motors, where its deep groove design handles radial loads efficiently. The C3 clearance ensures reliable performance even with thermal expansion.

In automotive applications, 6310 M/C3VL0241 Bearing fits well in wheel hubs and transmissions due to its durable chrome steel construction. Its metric sizing makes it a versatile choice for various vehicle models.

For automation systems, this bearing supports smooth operation in robotic arms and conveyor belts. The machined metal cage adds stability, making it suitable for high-speed environments.

Where Is 6310 M/C3VL0241 Bearing Used?
You’ll often find this bearing in household appliances like washing machines, where its robust design handles constant motion. The open seal type allows for easy maintenance and lubrication.

In agricultural equipment, 6310 M/C3VL0241 Bearing works well in gearboxes and harvesters. Its wide temperature range ensures performance in both hot and cold conditions.
