Flanged Deep Groove Ball Bearings W 627 R

Flanged Deep Groove Ball Bearings W 627 R

The W 627 R is a compact flanged deep groove ball bearing, measuring 7mm by 22mm with a 7mm width. Its stainless steel construction offers good resistance to wear and corrosion.

This bearing handles radial loads up to 447 lbf and can spin at speeds up to 48,000 RPM, making it suitable for fast-moving applications. The open design allows for easy lubrication when needed.

The integrated flange provides secure mounting, preventing slippage during operation. It operates in temperatures from -30°C to 120°C, adapting to various environments.

With its lightweight design at just 0.013kg, it’s ideal for small machinery or appliances where space is limited. Compliant with RoHS and REACH standards, it’s a reliable choice for various industrial uses.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number W 627 R
  • Brand TFL
  • Interchangeable SKF
  • System of Measurement Metric
  • Bearing Type Ball
  • For Load Direction Radial
  • Construction Single Row
  • Seal Type Open
  • Tolerance Class P0
  • Radial Clearance Trade No CN
  • Bore Dia 7 mm
  • Bore Dia Tolerance -0.008mm to 0
  • Outer Dia 22 mm
  • Outer Dia Tolerance -0.009mm to 0
  • Width 7 mm
  • Width Tolerance -0.12mm to 0
  • Flange Outer Dia 25 mm
  • Flange Thickness 1.5 mm
  • Ring Material Stainless Steel
  • Ball Material Stainless Steel
  • Cage Material Stainless Steel
  • Dynamic Radial Load 447 lbf
  • Static Radial Load 175 lbf
  • Max Speed 48000 rpm
  • Temperature Range -30° to 120 °C
  • RoHS Compliant
  • REACH Compliant
  • Weight 0.013 kg
  • Price（$） 2.1
Flanged Deep Groove Ball Bearings W 627 R dimension drawing
Download DWG Download PDF

Features

Why Choose W 627 R Bearing for Precision Tasks?

W 627 R Bearing features a stainless steel construction, offering excellent resistance to corrosion and wear.
Its compact size of 7 mm×25 mm×7 mm makes it ideal for applications where space is limited.

The open design allows for easy lubrication, ensuring smooth operation even at high speeds.
With a maximum speed of 48,000 rpm, it delivers reliable performance in precision instruments.

The flanged outer dia of 25 mm provides secure mounting, reducing the risk of misalignment.
W 627 R Bearing’s dynamic radial load capacity of 447 lbf ensures durability under stress.

Application

Industrial Uses of W 627 R Bearing
W 627 R Bearing is commonly used in small industrial motors and pumps, where its compact size and stainless steel construction offer reliable performance. The flange design ensures easy mounting and secure positioning in tight spaces.

Where Is W 627 R Bearing Used?
You’ll often find W 627 R Bearing in automotive applications like electric window mechanisms or small gearboxes. Its high-speed capability and corrosion resistance make it a dependable choice for these components.

Built for Versatility: W 627 R Bearing
W 627 R Bearing works well in consumer electronics, such as cooling fans or small appliances. The open design allows for efficient airflow, while the stainless steel materials ensure longevity.

Medical vs Industrial: Where W 627 R Bearing Excels
In medical devices like handheld diagnostic tools, W 627 R Bearing provides smooth, quiet operation. Its precision and cleanability also make it suitable for lab equipment where hygiene matters.

Perfect Fit for Automation: W 627 R Bearing
W 627 R Bearing is ideal for robotic arms and small conveyor systems in automated production lines. The lightweight design and high-speed performance help maintain efficiency in repetitive tasks.
