Drawn Cup Needle Roller Bearings SCE3216

Drawn Cup Needle Roller Bearings SCE3216

The SCE3216 is a drawn cup needle roller bearing with a 2-inch bore and 2.375-inch outer diameter, crafted from sturdy steel. It handles radial loads up to 933 lbf and operates smoothly at speeds up to 5100 RPM.
Its open-end design and press-fit mounting make installation straightforward, while the steel cage ensures durability. The bearing requires regular lubrication for optimal performance.
This model is interchangeable with INA bearings, offering a reliable alternative for replacements. Suitable for applications like automotive components or industrial machinery where radial loads are prevalent.
With a temperature range of -20°C to 110°C, it performs well in various environments. Compliant with RoHS standards for safe use.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number SCE3216
  • Brand TFL
  • Interchangeable INA
  • Bore Dia 2"
  • Bore Dia Tolerance Refer to note on the right drawing
  • Outer Dia 2.375"
  • Outer Dia Tolerance Not Rated
  • Width 1"
  • Width Tolerance -0.01" to 0"
  • System of Measurement Inch
  • Bearing Type Roller
  • Roller Bearing Type Needle
  • For Load Direction Radial
  • Construction Single Row
  • Seal Type Open
  • Series Open End
  • Ring Material Steel
  • Ball Material Steel
  • Cage Material Steel
  • Dynamic Radial Load 933 lbf
  • Static Radial Load 17985 lbf
  • Lubrication Required
  • Shaft Mount Type Press Fit
  • Temperature Range -20 to 110 °C
  • RoHS Compliant
  • Max Speed 5100 rpm
  • Weight 102 g
Drawn Cup Needle Roller Bearings SCE3216 dimension drawing
Download DWG Download PDF

Features

How Does SCE3216 Bearing Handle Radial Loads?
SCE3216 Bearing is built with steel rings and needles, offering robust resistance to radial loads.
Its dynamic radial load capacity reaches 933 lbf, making it suitable for various industrial applications.
The open-end design allows for easy press-fit installation, saving time and effort.
With a maximum speed of 5,100 rpm, it delivers reliable performance in demanding conditions.
SCE3216 Bearing operates efficiently within a temperature range of -20 to 110°C.
Regular lubrication ensures smooth operation and extends the bearing’s service life.

Application

Common Applications of SCE3216 Bearing
SCE3216 Bearing is widely used in industrial equipment like conveyor systems and printing presses, where its compact design handles high radial loads efficiently. The open-end construction simplifies installation in tight spaces.
In automotive applications, SCE3216 Bearing fits well in gearboxes and steering mechanisms, offering reliable performance under constant motion. Its press-fit mounting ensures a secure connection during high-speed operation.
For automation projects, SCE3216 Bearing works smoothly in robotic arms and assembly line equipment. The steel construction provides durability while maintaining precision in repetitive tasks.
You’ll also find SCE3216 Bearing in household appliances like washing machines, where its needle roller design reduces friction. The inch sizing makes it compatible with many North American products.
