Drawn Cup Needle Roller Bearings SCE2424-PP

Drawn Cup Needle Roller Bearings SCE2424-PP

The SCE2424-PP is a drawn cup needle roller bearing with a 1.5″ bore and 1.875″ outer diameter, made from sturdy steel for reliable performance. It handles radial loads up to 10678 lbf and operates smoothly at speeds up to 5500 RPM.
Its double-seal design keeps contaminants out and lubrication in, extending the bearing’s lifespan. The press-fit shaft mount ensures a secure and stable installation.
This bearing is ideal for applications like automotive components or industrial machinery where space is limited but high radial load capacity is needed. It’s interchangeable with INA bearings for easy replacements.
With a temperature range of -20°C to 110°C, it’s suitable for various environments. Compliant with RoHS standards, it’s a safe and durable choice for demanding tasks.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number SCE2424-PP
  • Brand TFL
  • Interchangeable INA
  • Bore Dia 1.5"
  • Bore Dia Tolerance Refer to note on the right drawing
  • Outer Dia 1.875"
  • Outer Dia Tolerance Not Rated
  • Width 1.5"
  • Width Tolerance -0.01" to 0"
  • System of Measurement Inch
  • Bearing Type Roller
  • Roller Bearing Type Needle
  • For Load Direction Radial
  • Construction Single Row
  • Seal Type Double Seal
  • Series Open End
  • Ring Material Steel
  • Ball Material Steel
  • Cage Material Steel
  • Dynamic Radial Load 10678 lbf
  • Static Radial Load 19334 lbf
  • Lubrication Required
  • Shaft Mount Type Press Fit
  • Temperature Range -20 to 110 °C
  • RoHS Compliant
  • Max Speed 5500 rpm
  • Weight 117 g
Drawn Cup Needle Roller Bearings SCE2424-PP dimension drawing
Download DWG Download PDF

Features

How Does SCE2424-PP Bearing Reduce Friction?
SCE2424-PP Bearing features a double-sealed design, keeping contaminants out and lubrication in for smooth operation.
Its steel construction ensures durability while handling dynamic radial loads up to 10678 lbf.
The needle roller design minimises friction, making SCE2424-PP Bearing ideal for high-speed applications.
With a maximum speed of 5500 rpm, it delivers reliable performance in various conditions.
SCE2424-PP Bearing’s press-fit shaft mount simplifies installation, saving time and effort.
Its temperature range of -20 to 110°C allows for consistent operation in diverse environments.

Application

Industrial Uses of SCE2424-PP Bearing
SCE2424-PP Bearing is commonly used in industrial gearboxes, where its compact design and high radial load capacity make it ideal for space-constrained applications. The double seal helps keep contaminants out, extending the bearing’s lifespan in harsh environments.
Where Is SCE2424-PP Bearing Used?
You’ll often find SCE2424-PP Bearing in automotive transmissions, where its press-fit design ensures a secure mount under high-speed conditions. The steel construction provides durability, making it a reliable choice for long-term use.
Built for Heavy-Duty Use: SCE2424-PP Bearing
SCE2424-PP Bearing excels in construction equipment like hydraulic pumps, handling heavy radial loads with ease. Its inch sizing makes it compatible with many North American machinery standards.
Automotive vs Industrial: Applications of SCE2424-PP Bearing
In automotive steering systems, SCE2424-PP Bearing offers smooth operation, while in industrial conveyors, it handles continuous radial loads. The steel cage ensures stability across both applications.
Perfect Fit for Automation: SCE2424-PP Bearing
SCE2424-PP Bearing works well in robotic arms, where its precision and low maintenance requirements are key. The double-sealed design keeps lubrication in and dirt out, even in high-use scenarios.
