Drawn Cup Needle Roller Bearings BCE610

Brand: TFL Bearing Interchangeable: INA BCE610 0.375" × 0.5625" × 0.625" Inch Open
Part number: BCE610
Drawn Cup Needle Roller Bearings BCE610
In Stock
Price on request
Send your part number and quantity for a quote
Get a Quote WhatsApp
  • ISO 9001 quality system
  • RoHS & REACH compliant
  • Pre-shipment inspection
  • Lead time confirmed with your quote
Dimensions
Bore Dia0.375"
Bore Dia ToleranceRefer to note on the right drawing
Outer Dia0.5625"
Outer Dia ToleranceNot Rated
Width0.625"
Width Tolerance-0.01" to 0"
Performance
Dynamic Radial Load1,664 lbf
Static Radial Load2,046 lbf
Temperature Range-20 to 110 °C
Max Speed25,000 rpm
Characteristics
System of MeasurementInch
Bearing TypeRoller
Roller Bearing TypeNeedle
For Load DirectionRadial
ConstructionSingle Row
Seal TypeOpen
SeriesClosed End
LubricationRequired
Shaft Mount TypePress Fit
Weight7 g
Material
Ring MaterialSteel
Ball MaterialSteel
Cage MaterialSteel
Compliance
RoHSCompliant
Dimension drawing · click to enlarge

Description

The BCE610 is a drawn cup needle roller bearing with a 0.375″ bore and 0.5625″ outer diameter, crafted from sturdy steel for reliable performance. It handles radial loads up to 1664 lbf and spins efficiently at speeds up to 25000 RPM.
Its open, single-row design with a press-fit shaft mount ensures easy installation and maintenance. The steel cage and rollers provide durability under heavy use.
This bearing operates well in temperatures from -20°C to 110°C and requires regular lubrication for optimal performance. It’s interchangeable with INA bearings, making it a practical choice for replacements.
Ideal for applications like automotive components or small machinery where space is limited but high radial load capacity is needed. RoHS compliant for safe and eco-friendly use.

Features

Why Choose BCE610 Bearing for Precision Tasks?
BCE610 Bearing is crafted with steel rings and needles, offering excellent radial load capacity up to 1664 lbf.
Its press-fit shaft mount ensures secure installation, reducing the risk of slippage during operation.
The bearing operates smoothly at speeds up to 25,000 rpm, making it suitable for high-performance applications.
With a temperature range of -20 to 110°C, it remains reliable in various working conditions.

Application

Industrial Uses of BCE610 Bearing
BCE610 Bearing is commonly used in industrial machinery, especially in compact spaces where high radial load capacity is needed, like conveyor rollers and printing presses. Its steel construction ensures durability in demanding environments.
Where Is BCE610 Bearing Used?
You’ll often find BCE610 Bearing in automotive applications, such as gearboxes and transmission systems, where its press-fit design provides a secure and stable fit. The high-speed capability makes it suitable for performance-driven components.
Built for Heavy-Duty Use: BCE610 Bearing
In automation and robotics, BCE610 Bearing supports precise movements in robotic arms and linear actuators. Its open design allows for easy lubrication, ensuring smooth operation over long periods.
Medical vs Industrial: Where BCE610 Bearing Excels
While BCE610 Bearing isn’t typically used in medical devices, it shines in industrial settings like packaging machines, where reliability and speed are key. The inch sizing makes it a versatile choice for various equipment.
Perfect Fit for Automation: BCE610 Bearing
For consumer electronics, BCE610 Bearing can be found in small motors and power tools, where its compact size and high load capacity are advantageous. The steel cage adds extra strength for prolonged use.
