Flanged Deep Groove Ball Bearings
The Flanged Deep Groove Ball Bearings have a flange on the outer ring, which is relatively easy to locate axially in the bearing seat, making it easier and more cost-effective to manufacture the bearing hole.
Loading...
Total 199 Results
Part Number
System of Measurement
Seal Type
Bore Dia
Outer Dia
Width
Dynamic Radial Load
Static Radial Load
Max Speed
Weight
Price($)
D/W R3 R-2RS1
Inch
Sealed
0.18748"
0.5"
0.19598"
167 lbf
56 lbf
32000 rpm
0.0031 kg
1.3
D/W R3 R-2Z
Inch
Shielded
0.18748"
0.5"
0.19598"
167 lbf
56 lbf
56000 rpm
0.003 kg
1.3
D/W R3W.1562 R
Inch
Open
0.18748"
0.5"
0.15618"
167 lbf
56 lbf
70000 rpm
0.0024 kg
1.3
D/W R168 R
Inch
Open
0.25"
0.375"
0.125"
48 lbf
20 lbf
75000 rpm
0.0006 kg
1.3
D/W R168 R-2Z
Inch
Shielded
0.25"
0.375"
0.125"
48 lbf
20 lbf
60000 rpm
0.0007 kg
1.3
D/W R168 R-2ZS
Inch
Shielded
0.25"
0.375"
0.125"
48 lbf
20 lbf
60000 rpm
0.000714 kg
1.3
D/W R188 R
Inch
Open
0.25"
0.5"
0.125"
139 lbf
50 lbf
67000 rpm
0.0016 kg
1.3
D/W R188 R-2Z
Inch
Shielded
0.25"
0.5"
0.18748"
139 lbf
50 lbf
53000 rpm
0.0023 kg
1.3
D/W R4 R
Inch
Open
0.25"
0.625"
0.19598"
192 lbf
71 lbf
60000 rpm
0.0042 kg
1.3
D/W R4 R-2RS1
Inch
Sealed
0.25"
0.625"
0.19598"
192 lbf
71 lbf
28000 rpm
0.0045 kg
1.3
D/W R4 R-2Z
Inch
Shielded
0.25"
0.625"
0.19598"
192 lbf
71 lbf
48000 rpm
0.0046 kg
1.3
D/W R1810 R
Inch
Open
0.31252"
0.5"
0.15618"
70 lbf
32 lbf
63000 rpm
0.0015 kg
1.3
D/W R1810 R-2ZS
Inch
Shielded
0.31252"
0.5"
0.15618"
70 lbf
32 lbf
50000 rpm
0.0016 kg
1.3
D/W R6 R
Inch
Open
0.375"
0.875"
0.21882"
555 lbf
252 lbf
45000 rpm
0.0097 kg
1.3
The Structures of Flange Ball Bearings
The whole structure of flange ball bearings is simple. Due to the integrated structure of the flanged outer ring, which is convenient for installation and maintenance, it will be directly connected to other components, which can reduce additional installation steps and parts, thereby reducing installation costs;
Their simplified housing lowers costs, and versatility in handling combined loads suits gearboxes and robotics. Optional seals improve durability by excluding contaminants and retaining lubricant, extending service life in demanding industrial settings. These features make flanged bearings a robust, space-efficient solution for applications prioritizing reliability and ease of maintenance.
Advantages of Flanged Ball Bearing
Flanged bearings that use balls as rolling elements have a lower friction coefficient than sliding modes. This reduces wear and power consumption, makes high speed, and ensures the service life of the bearing.
TFL Bearing offers a wide variety of high-quality bearings. Our bearings can be replaced with those of mainstream brands. You can select the bearings you need from our product page.
Applications of Flange Bearings
Flanged bearings can withstand large axial, radial loads and torques, they are suitable for various types of mechanical equipment and working environments.
Whether it is heavy equipment on industrial production lines or small components in precision instruments, you can find suitable flange bearings to meet your needs.
FREQUENTLY ASKED QUESTIONS
What is the common way to represent flange in bearing models?
Generally speaking, the model of flange bearing is composed of letter F + ordinary deep groove ball bearing model;
For example:
NSK brand flange deep groove ball bearing F686ZZ;
EZO brand miniature flange deep groove ball bearing MF93ZZ;
NB brand inch flange deep groove ball bearing FR2-5ZZ;
Click here to view the flanged ball bearing size chart, to query all models and find the required bearings.
What kinds of flange ball bearings are divided into based on the raw material?
Flange bearings are the same as deep groove ball bearings, and can be made of a variety of raw materials:
GCR15 bearings: The entire body is made of bearing steel that meets international standards;
Stainless steel bearings: The inner and outer rings and rolling elements are all made of stainless steel to be suitable for humid environments;
Ceramic bearings: Usually, the inner and outer rings are made of stainless steel or bearing steel, and the balls are made of ceramic to achieve a higher speed;
Plastic bearings: The entire body is made of plastic, and there may also be a combination of glass or ceramic balls.
Where can I buy ball bearings?
Welcome to TFL bearing's website, we offer various series of ball bearings, deep groove ball bearings, flange deep groove ball bearings and ceramic hybrid ball bearings of all sizes.
We can provide SKF replacements of the same quality. Please send us the bearing models, bearing drawings, or bearing sizes, and let us help you.
Do you offer samples? What is the Minimum Order Quantity (MOQ)?
Sample availability and Minimum Order Quantity (MOQ) can vary by product model. Please check the specific product page or contact our sales team for details on the bearing you need.
