Flanged Deep Groove Ball Bearings D/W R3 R-2RS1

Flanged Deep Groove Ball Bearings D/W R3 R-2RS1

The D/W R3 R-2RS1 is a flanged deep groove ball bearing with a compact size of 0.18748″×0.565″×0.19598″, made entirely from stainless steel for durability. It handles radial loads up to 167 lbf and spins smoothly at speeds up to 32,000 RPM.

Its sealed design keeps grease in and contaminants out, making it low-maintenance. The flange adds stability, helping the bearing stay securely in place during operation.

This bearing works well in temperatures from -30°C to 120°C, suitable for various environments. It’s interchangeable with SKF models, offering a reliable replacement option.

Ideal for small machinery or instruments where space is limited but performance is key. Weighing just 0.0031kg, it’s lightweight yet sturdy for its size. Compliant with RoHS and REACH standards.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number D/W R3 R-2RS1
  • Brand TFL
  • Interchangeable SKF
  • System of Measurement Inch
  • Bearing Type Ball
  • For Load Direction Radial
  • Construction Single Row
  • Seal Type Sealed
  • Tolerance Class P0
  • Radial Clearance Trade No CN
  • Bore Dia 0.18748"
  • Bore Dia Tolerance -0.00019" to 0.00019"
  • Outer Dia 0.5"
  • Outer Dia Tolerance -0.0007" to -0.00031"
  • Width 0.19598"
  • Width Tolerance -0.005" to 0"
  • Flange Outer Dia 0.565"
  • Flange Thickness 0.04201"
  • Ring Material Stainless Steel
  • Ball Material Stainless Steel
  • Cage Material Stainless Steel
  • Dynamic Radial Load 167 lbf
  • Static Radial Load 56 lbf
  • Max Speed 32000 rpm
  • Temperature Range -30° to 120 °C
  • Lubrication Grease
  • RoHS Compliant
  • REACH Compliant
  • Weight 0.0031 kg
  • Price（$） 1.3
Flanged Deep Groove Ball Bearings D/W R3 R-2RS1 dimension drawing
Download DWG Download PDF

Features

Why Choose D/W R3 R-2RS1 Bearing for Precision Tasks?

D/W R3 R-2RS1 Bearing features a stainless steel construction, ensuring resistance to corrosion and wear.
Its sealed design keeps contaminants out, making it ideal for precision applications.
The bearing handles dynamic radial loads up to 167 lbf, providing reliable performance.
With a maximum speed of 32,000 rpm, it offers smooth operation in high-speed environments.

How Is D/W R3 R-2RS1 Bearing Engineered for Reliability?

D/W R3 R-2RS1 Bearing’s single-row design and sealed construction enhance its durability.
The stainless steel cage and balls reduce friction, ensuring long-lasting performance.
Its tolerance class P0 ensures precise operation, even under demanding conditions.
The bearing operates efficiently within a temperature range of -30° to 120°C.

Built for Efficiency: D/W R3 R-2RS1 Bearing

D/W R3 R-2RS1 Bearing is designed with a flange for easy mounting and alignment.
Its grease lubrication reduces maintenance needs while ensuring smooth operation.
The bearing’s compact size and lightweight design make it suitable for various applications.
With a static radial load capacity of 56 lbf, it provides reliable support in radial load scenarios.

Application

Common Applications of D/W R3 R-2RS1 Bearing
D/W R3 R-2RS1 Bearing is a great fit for small electric motors, thanks to its compact inch sizing and sealed design. The stainless steel construction ensures it handles everyday wear without fuss.

In household appliances like blenders or mixers, D/W R3 R-2RS1 Bearing offers quiet operation and reliable performance. Its grease lubrication keeps things running smoothly for years.

For light industrial tools, D/W R3 R-2RS1 Bearing’s flange provides extra stability in tight spaces. The sealed design also helps keep out dust and debris, extending its lifespan.

Where Is D/W R3 R-2RS1 Bearing Used?
You’ll often spot D/W R3 R-2RS1 Bearing in office equipment like printers, where its small size and precision matter. The stainless steel balls ensure consistent movement even with frequent use.

In hobbyist projects, D/W R3 R-2RS1 Bearing is handy for DIY robotics due to its lightweight and durability. The sealed design means less maintenance, so you can focus on building.

Built for Heavy-Duty Use: D/W R3 R-2RS1 Bearing
D/W R3 R-2RS1 Bearing works well in conveyor systems, handling light radial loads with ease. The flange design helps with quick installation and alignment.

For medical devices like small pumps, D/W R3 R-2RS1 Bearing’s stainless steel material meets hygiene standards. Its sealed construction also prevents contamination in sensitive environments.
