Single Row Angular Contact Ball Bearings (General)
Super precision angular contact ball bearings are engineered for high-speed, high-accuracy applications such as machine tools, aerospace systems, and robotics.
Loading...
Total 600 Results
Part Number
Interchangeable
System of Measurement
Contact Angle
For Load Direction
Bore Dia
Outer Dia
Width
External Diameter On Inner Ring (Small Side Face)
Dynamic Radial Load
Static Radial Load
Price($)
7307 BEGAP
SKF
Metric
40°
Angular Contact
35 mm
80 mm
21 mm
43.62 mm
9338 lbf
5962 lbf
23.18
7307 BEGAPH
SKF
Metric
40°
Angular Contact
35 mm
80 mm
21 mm
43.62 mm
9338 lbf
5962 lbf
7307 BEGBP
SKF
Metric
40°
Angular Contact
35 mm
80 mm
21 mm
43.62 mm
9338 lbf
5962 lbf
26.55
7307 BEP
SKF
Metric
40°
Angular Contact
35 mm
80 mm
21 mm
43.62 mm
8775 lbf
5512 lbf
22.92
7407 BCBM
SKF
Metric
40°
Angular Contact
35 mm
100 mm
25 mm
50.75 mm
13612 lbf
8550 lbf
36.95
7407 BM
SKF
Metric
40°
Angular Contact
35 mm
100 mm
25 mm
50.75 mm
13612 lbf
8550 lbf
38.72
7208 ACCBM
SKF
Metric
25°
Angular Contact
40 mm
80 mm
18 mm
48.08 mm
9338 lbf
6525 lbf
7208 BE-2RZP
SKF
Metric
40°
Angular Contact
40 mm
80 mm
18 mm
48.05 mm
7762 lbf
5400 lbf
7208 BECBJ
SKF
Metric
40°
Angular Contact
40 mm
80 mm
18 mm
48.08 mm
8212 lbf
5850 lbf
21.14
7208 BECBM
SKF
Metric
40°
Angular Contact
40 mm
80 mm
18 mm
48.08 mm
8212 lbf
5850 lbf
21.98
7208 BECBP
SKF
Metric
40°
Angular Contact
40 mm
80 mm
18 mm
48.08 mm
8212 lbf
5850 lbf
21.71
7208 BECBPH
SKF
Metric
40°
Angular Contact
40 mm
80 mm
18 mm
48.08 mm
8212 lbf
5850 lbf
7208 BECBY
SKF
Metric
40°
Angular Contact
40 mm
80 mm
18 mm
48.08 mm
8212 lbf
5850 lbf
18.29
7208 BEGAP
SKF
Metric
40°
Angular Contact
40 mm
80 mm
18 mm
48.08 mm
8212 lbf
5850 lbf
19.92
Supports Combined Loads Efficiently
Single row angular contact ball bearing is a basic type of bearing, designed to accommodate both radial and significant axial loads simultaneously, but only in one direction for a single bearing.
The internal geometry features offset raceways creating a contact angle, enabling this crucial capability. This makes them an ideal choice for applications where both load types are present and need reliable management, such as in pumps and compressors.
Select these when simple radial bearings aren’t enough.
Variety of Contact Angles Available
These angular contact bearings are available with different standard contact angles (commonly 15°, 25°, 30°, 40°). Different contact angles result in different performance: larger angle provides higher axial load capacity but generally lower speed capability, while smaller angle offers higher speed potential but lower axial capacity.
Choose the contact angle that best balances the axial load magnitude and operational speed requirements for your specific machinery, ensuring optimal performance and lifespan.
Versatile Choice Among Bearing Types
As a widely used type of bearing, single row angular contact ball bearings offer a versatile solution for many industrial applications like gearboxes, electric motors, and machine tool components where combined loads occur.
While a double row angular contact ball bearing offers bidirectional axial support in one unit, single row bearings provide more flexibility in arrangement and preload control. They represent a reliable and cost-effective choice for numerous standard engineering challenges.
FREQUENTLY ASKED QUESTIONS
Why can a single bearing only take axial load one way?
Because the internal raceways are offset relative to each other, creating an angle. Load is transmitted along this angle, meaning axial force can only be properly supported in one direction based on how the bearing is oriented.
What's the main difference between single row angular contact ball bearings vs. double row angular contact ball bearing?
A single row bearing has one row of balls and handles axial load in one direction (when used alone).
A double row angular contact ball bearing has two rows, typically arranged internally like a DB pair, handling bidirectional axial loads in a single, more compact unit.
How do I choose the right contact angle when buying?
Consider your load ratio and speed. Higher axial load component suggests a larger angle (e.g., 40°). Higher speed requirements favor a smaller angle (e.g., 25°). Consult product detail pages.
