Single Row Angular Contact Ball Bearings (General) 7208 BECBM

Single Row Angular Contact Ball Bearings (General) 7208 BECBM

The 7208 BECBM is a single-row angular contact ball bearing with a 40mm bore and 80mm outer diameter, crafted from sturdy chrome steel. It handles radial loads up to 8212 lbf and operates smoothly at speeds up to 13,000 RPM.

With a 40° contact angle, it efficiently manages combined radial and axial loads. The open design allows easy lubrication, while the brass cage enhances durability and reduces friction.

This bearing is interchangeable with SKF models, making it a practical choice for replacements. Suitable for applications like pumps or gearboxes where precise load handling is needed.

Weighing 0.37kg, it’s compact yet robust. Compliant with RoHS and REACH standards, it performs reliably in temperatures from -30°C to 110°C.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number 7208 BECBM
  • Brand TFL
  • Interchangeable SKF
  • System of Measurement Metric
  • Bearing Type Ball
  • Contact Angle 40°
  • For Load Direction Angular Contact
  • Construction Single Row
  • Seal Type Open
  • Bore Dia 40 mm
  • Bore Dia Tolerance -0.01mm to 0
  • Outer Dia 80 mm
  • Outer Dia Tolerance -0.011mm to 0
  • Width 18 mm
  • Width Tolerance -0.05mm to 0
  • External Diameter On Inner Ring (Large Side Face) 56.25 mm
  • External Diameter On Inner Ring (Small Side Face) 48.08 mm
  • Internal Diameter On Outer Ring 65.55 mm
  • Chamfer Dimension 1.1 mm
  • Distance Pressure Point (a) 34 mm
  • Ring Material Chrome Steel
  • Ball Material Chrome Steel
  • Cage Material Brass
  • Dynamic Radial Load 8212 lbf
  • Static Radial Load 5850 lbf
  • Lubrication Lubricated
  • Temperature Range -30° to 110 °C
  • Tolerance Class P6 (ABEC-3)
  • ROHS Compliant
  • REACH Compliant
  • Max Speed 13000 rpm
  • Weight 0.37 kg
  • Price（$） 21.98
Single Row Angular Contact Ball Bearings (General) 7208 BECBM dimension drawing
Download DWG Download PDF

Features

Performance Features of 7208 BECBM Bearing

7208 BECBM Bearing features a 40° contact angle, optimised for handling combined radial and axial loads.
Its chrome steel construction ensures durability, while the brass cage maintains ball alignment for smooth operation.

The bearing supports dynamic radial loads up to 8212 lbf, making it suitable for high-performance applications.
With a maximum speed of 13,000 rpm, it delivers reliable performance in demanding conditions.

7208 BECBM Bearing operates efficiently within a temperature range of -30° to 110°C.
Its P6 tolerance class (ABEC-3) ensures precision and consistency in various industrial uses.

Application

Industrial Uses of 7208 BECBM Bearing
7208 BECBM Bearing is commonly used in machine tools, where its 40° contact angle efficiently handles combined radial and axial loads. The brass cage ensures smooth operation even at high speeds, making it suitable for precision equipment.

Where Is 7208 BECBM Bearing Used?
In automotive applications, 7208 BECBM Bearing supports components like wheel hubs and transmissions, thanks to its durable chrome steel construction. Its P6 tolerance class ensures reliable performance in demanding conditions.

Built for Heavy-Duty Use: 7208 BECBM Bearing
7208 BECBM Bearing excels in conveyor systems, where its open design allows for easy lubrication and maintenance. The metric sizing makes it a versatile choice for various industrial setups.

Automotive vs Aerospace: Applications of 7208 BECBM Bearing
7208 BECBM Bearing is ideal for automotive gearboxes, offering stability under angular loads. In aerospace, its high-speed capability and brass cage make it suitable for auxiliary equipment.

Perfect Fit for Automation: 7208 BECBM Bearing
7208 BECBM Bearing works well in robotic arms, where its precision and load-handling capacity are crucial. The lubricated design ensures long service life in continuous operation.
