TS (Single Row Tapered Roller Bearings) (Metric) X33215-Y33215

The 396A-394AB is a single-row tapered roller bearing with a flange, measuring 1.7712″ x 4.3307″ x 0.866″. Made from durable chrome steel, it handles combined loads up to 22200 lbf radially and 3970 lbf thrust.

Its flanged cup design keeps it securely in place, while the open seal allows for easy lubrication. The steel cage ensures smooth operation even under heavy loads.

This bearing is interchangeable with Timken models, making it a practical choice for replacements. It works well in temperatures from -30°C to 110°C.

Ideal for industrial machinery or automotive applications where combined loads are common. Compliant with RoHS and REACH standards, it weighs 2.5 lb for easy handling.

Get A Free Quote

Description

Features

Application

Q&A

Product Parameters

Part Number X33215-Y33215
Brand TFL
Interchangeable Brand Timken
System of Measurement Metric
Type Bearing
Sizes 75 mm x 130 mm x 41 mm
Cone Part Number X33215
Cup Part Number Y33215
Bore Dia 75 mm
Bore Dia Tolerance -0.015mm to 0
Outer Dia 130 mm
Outer Dia Tolerance -0.02mm to 0
Cone Width 41 mm
Cone Width Tolerance -0.15mm to 0
Cup Width 31 mm
Cup Width Tolerance -0.2mm to 0
Width 41 mm
Width Tolerance +0.2mm to 0
Cone Backface ToClear Radius 2.03 mm
Cup Backface ToClear Radius 1.52 mm
Cone Frontface Backing Diameter 83 mm
Cone Backface Backing Diameter 89 mm
Cup Frontface Backing Diameter 125.00 mm
Cup Backface Backing Diameter 117.09 mm
Cage Cone Frontface Clearance 3.6 mm
Cage Cone Backface Clearance 3.6 mm
Effective Center Location -8.6 mm
Bearing Type Roller
Roller Bearing Type Tapered
For Load Direction Combined
Construction Single Row
Seal Type Open
Cups Type Standard
Series 33215
Ring Material Chrome Steel
Roller Material Chrome Steel
Cage Material Steel
Dynamic Radial Load 53100 lbf
Static Radial Load 71100 lbf
Dynamic Radial Rating(90 Million Revolutions)(C90) 13770 lbf
Dynamic Thrust Rating(90 Million Revolutions)(Ca90) 10102.5 lbf
Lubrication Required
Temperature Range -30° to 110 °C
ABEC Rating ABEC-1
Radial Clearance Standard (Available in C3/C4/C5)
RoHS Compliant
REACH Compliant
Weight 4.85 lb

Features

Performance Features of 396A-394AB Bearing

396A-394AB Bearing is built with chrome steel rings and rollers, offering strong resistance to combined loads.
Its dynamic radial load capacity reaches 22,200 lbf, ensuring reliable performance in heavy-duty applications.

The flanged cup design provides better alignment and stability during operation.
With a standard radial clearance, it suits various industrial needs without compromising efficiency.

396A-394AB Bearing operates effectively in temperatures from -30° to 110°C.
Its steel cage maintains roller alignment, reducing friction and extending service life.

The tapered roller design ensures smooth operation under both radial and thrust loads.
This makes 396A-394AB Bearing a versatile choice for demanding environments.

Application

Industrial Uses of 396A-394AB Bearing
The 396A-394AB Bearing is commonly used in heavy machinery like construction equipment, where its tapered roller design handles combined loads efficiently. The flanged cup adds stability, making it ideal for applications with axial movement.

In automotive systems, 396A-394AB Bearing fits well in wheel hubs and differentials, thanks to its durable chrome steel construction. Its inch sizing ensures compatibility with many American and British vehicle models.

For conveyor systems, 396A-394AB Bearing’s open design allows easy lubrication, extending service life in dusty environments. The steel cage provides extra strength for high-load scenarios.

Where Is 396A-394AB Bearing Used?
You’ll often find 396A-394AB Bearing in agricultural machinery, where its robust design withstands rough conditions. The tapered rollers distribute loads evenly, reducing wear over time.

In industrial fans, 396A-394AB Bearing’s flanged cup keeps it securely in place during high-speed operation. The chrome steel rollers ensure smooth performance even under continuous use.

Built for Heavy-Duty Use: 396A-394AB Bearing
The 396A-394AB Bearing excels in mining equipment, handling both radial and thrust loads with ease. Its standard radial clearance offers flexibility for various operating conditions.

For gearboxes, 396A-394AB Bearing’s precise tolerances ensure reliable power transmission. The steel cage adds durability, making it a long-lasting choice for demanding applications.

Automotive vs Aerospace: Applications of 396A-394AB Bearing
In automotive drivetrains, 396A-394AB Bearing provides reliable performance under heavy loads. Its inch measurements make it a go-to for classic car restorations.

For aerospace ground equipment, 396A-394AB Bearing’s temperature range suits outdoor use. The flanged design prevents misalignment during transport and handling.
