TS (Single Row Tapered Roller Bearings) (Imperial) H247548-H247510

TS (Single Row Tapered Roller Bearings) (Imperial) H247548-H247510

The H247548-H247510 is a single-row tapered roller bearing with a 9.25″ bore and 15.125″ outer diameter, built from sturdy chrome steel. It handles combined loads up to 422,000 lbf and is designed for long-lasting performance.

Its pin-type cage ensures smooth operation, while the open design allows easy lubrication. The bearing works in temperatures from -30°C to 110°C, making it suitable for tough conditions.

This model is interchangeable with Timken bearings, offering a reliable replacement option. Ideal for heavy-duty applications like industrial machinery or large vehicles where high radial and thrust loads are common.

Weighing 113.8 lb, it’s a robust choice for demanding environments. Compliant with RoHS and REACH standards for safe use.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number H247548-H247510
  • Brand TFL
  • Interchangeable Timken
  • Size 9.25" x 15.125" x 4.4375"
  • Bore Dia 9.25"
  • Bore Dia Tolerance +0.001" to 0
  • Outer Dia 15.125"
  • Outer Dia Tolerance +0.002" to 0
  • Cone Width 4.4375"
  • Cone Width Tolerance +0.003" to -0.01
  • Cup Width 3.5625"
  • Cup Width Tolerance +0.002" to -0.01
  • Width 4.4375"
  • Width Tolerance +0.014" to -0.01"
  • Cone Backface ToClear Radius 0.25"
  • Cup Backface ToClear Radius 0.250"
  • Cone Frontface Backing Diameter 11.33"
  • Cone Backface Backing Diameter 10.59"
  • Cup Frontface Backing Diameter 14.32"
  • Cup Backface Backing Diameter 13.62"
  • Cage Cone Frontface Clearance 0.22"
  • Cage Cone Backface Clearance 0.27"
  • Effective Center Location -1.1"
  • System of Measurement Inch
  • Type Bearing
  • Cone Part Number H247548
  • Cup Part Number H247510
  • Bearing Type Roller
  • Roller Bearing Type Tapered
  • For Load Direction Combined
  • Construction Single Row
  • Seal Type Open
  • Cups Type Standard
  • Series H247500
  • Ring Material Chrome Steel
  • Roller Material Chrome Steel
  • Cage Material Pin-Type
  • Dynamic Radial Load 422000 lbf
  • Static Radial Load 757000 lbf
  • Dynamic Radial Rating(90 Million Revolutions)(C90) 109000 lbf
  • Dynamic Thrust Rating(90 Million Revolutions)(Ca90) 62200 lbf
  • Lubrication Required
  • Temperature Range -30° to 110 °C
  • ABEC Rating ABEC-1
  • Radial Clearance Standard (Available in C3/C4/C5)
  • RoHS Compliant
  • REACH Compliant
  • Weight 113.800 lb

Features

How Does H247548-H247510 Bearing Handle Combined Loads?

H247548-H247510 Bearing is built with chrome steel rings and rollers, offering strong resistance to both radial and thrust loads.
Its dynamic radial load capacity reaches 422,000 lbf, ensuring reliable performance in heavy-duty applications.

The pin-type cage keeps the rollers aligned, reducing friction and extending service life.
With a temperature range of -30° to 110°C, it performs well in various operating conditions.

H247548-H247510 Bearing requires lubrication, ensuring smooth operation and reduced wear over time.
Its standard radial clearance options provide flexibility for different application needs.

Application

Industrial Uses of H247548-H247510 Bearing
H247548-H247510 Bearing is commonly used in heavy machinery like mining equipment and construction vehicles, where its tapered roller design handles combined loads effectively. The chrome steel construction ensures durability even in tough working conditions.

What Makes H247548-H247510 Bearing a Preferred Choice?
In agricultural machinery, H247548-H247510 Bearing supports high radial loads in tractors and harvesters, thanks to its robust pin-type cage. Its inch sizing makes it compatible with many North American industrial applications.

Built for Heavy-Duty Use: H247548-H247510 Bearing
H247548-H247510 Bearing excels in railway applications, particularly in axle boxes where reliability is critical. The standard radial clearance allows for smooth operation under varying temperature conditions.

Automotive vs Aerospace: Applications of H247548-H247510 Bearing
In automotive drivetrains, H247548-H247510 Bearing manages thrust and radial loads efficiently, while in aerospace, its precision supports auxiliary systems. The ABEC-1 rating ensures consistent performance across both sectors.

Where Is H247548-H247510 Bearing Used?
You’ll often find H247548-H247510 Bearing in wind turbine gearboxes, where its dynamic load capacity handles unpredictable forces. The open design simplifies lubrication, extending service intervals in remote installations.
