Thrust Ball Bearing With Outside Band T-100-14

Thrust Ball Bearing With Outside Band T-100-14

The T-100-14 is a thrust ball bearing with a 1.1875-inch bore and 2.40625-inch outer diameter, crafted from durable 52100 chrome steel. It handles thrust loads up to 5505 lbf and performs well across various speeds, from 100 to 1500 RPM.

Its outside band design provides stability, while the 15 steel balls ensure smooth operation. The bearing requires regular lubrication for optimal performance.

This model is suitable for applications with moderate to high thrust loads, such as industrial machinery or automotive components. It operates reliably in temperatures ranging from -30°C to 110°C.

Weighing 0.34kg, it’s a sturdy yet manageable component. Compliant with RoHS and REACH standards, it’s a safe choice for various industries.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number T-100-14
  • Brand TFL
  • Bore Dia 1.187500"
  • Bore Dia Tolerance +0.001" to +0.003"
  • Inner Dia Housing Washer 1.218750"
  • Outer Dia 2.406250"
  • Outer Dia Tolerance -0.015" to +0.015"
  • Width 0.937500"
  • Width Tolerance -0.005" to +0.005"
  • Ball Dia 3/8"
  • Ball Qty 15
  • System of Measurement Inch
  • Bearing Type Ball
  • For Load Direction Thrust
  • Ring Material 52100 Chrome Steel
  • Ball Material 52100 Chrome Steel
  • Dynamic Thrust Load 5505 lbf
  • Dynamic Thrust Load(100 RPM) 3625 lbf
  • Dynamic Thrust Load(500 RPM) 2235 lbf
  • Dynamic Thrust Load(1500 RPM) 1605 lbf
  • Static Thrust Load 18847 lbf
  • Lubrication Required
  • Temperature Range -30° to 110 °C
  • RoHS Compliant
  • REACH Compliant
  • Weight 0.34 kg
Thrust Ball Bearing With Outside Band T-100-14 dimension drawing
Download DWG Download PDF

Features

How Does T-100-14 Bearing Handle Heavy Loads?

T-100-14 Bearing is built with 52100 chrome steel rings and balls, offering robust resistance to high thrust loads.
Its static thrust load capacity reaches 18,847 lbf, making it suitable for heavy-duty applications.

The bearing’s design includes 15 balls, each with a diameter of 3/8″, ensuring balanced load distribution.
This configuration enhances durability and reduces wear over time.

T-100-14 Bearing operates efficiently within a temperature range of -30° to 110°C.
Its inch-based measurements provide compatibility with systems requiring precise imperial specifications.

Application

Industrial Uses of T-100-14 Bearing
T-100-14 Bearing is commonly used in heavy machinery, such as hydraulic pumps and gearboxes, where its high thrust load capacity ensures reliable performance. The inch sizing makes it a good fit for equipment designed to imperial standards.

In automotive applications, T-100-14 Bearing handles axial loads in components like steering systems and transmissions. Its chrome steel construction provides durability under constant stress, making it a trusted choice for vehicle manufacturers.

For automation systems, T-100-14 Bearing supports robotic arms and conveyor belts, where precise movement is essential. The required lubrication helps maintain smooth operation over long periods, reducing downtime.

Where Is T-100-14 Bearing Used?
You’ll often find T-100-14 Bearing in industrial fans and compressors, where its ability to handle dynamic thrust loads keeps equipment running efficiently. The wide temperature range also makes it suitable for varied environments.

In medical devices like dental chairs, T-100-14 Bearing’s consistent performance ensures patient comfort and safety. The stainless steel components resist corrosion, which is crucial in sterile settings.

Built for Heavy-Duty Use: T-100-14 Bearing
T-100-14 Bearing excels in construction equipment, such as cranes and excavators, thanks to its robust design and high static thrust load rating. The tolerance ranges allow for precise fitting in demanding applications.

For home appliances like washing machines, T-100-14 Bearing provides quiet and efficient operation. Its balanced design reduces vibration, extending the lifespan of the appliance.
