Stainless Steel Deep Groove Ball Bearings W 626-2RS1

Stainless Steel Deep Groove Ball Bearings W 626-2RS1

The W 626-2RS1 is a compact stainless steel deep groove ball bearing, measuring 6mm by 19mm by 6mm. It handles radial loads up to 344 lbf and spins smoothly at speeds up to 24,000 RPM.

Its sealed design keeps grease in and dirt out, making it low-maintenance. The all-stainless construction resists corrosion, ideal for damp or harsh environments.

This bearing works well in temperatures from -30°C to 120°C. It’s interchangeable with SKF models, offering easy replacement options.

Perfect for small machinery, electric motors, or food processing equipment where hygiene matters. Weighing just 7.6 grams, it’s lightweight yet durable for its size. Compliant with RoHS and REACH standards.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number W 626-2RS1
  • Brand TFL
  • Interchangeable SKF
  • Bore Dia 6 mm
  • Bore Dia Tolerance -0.008mm to 0
  • Outer Dia 19 mm
  • Outer Dia Tolerance -0.009mm to 0
  • Width 6 mm
  • Width Tolerance -0.12mm to 0
  • System of Measurement Metric
  • Bearing Type Ball
  • For Load Direction Radial
  • Construction Single Row
  • Seal Type Sealed
  • Tolerance Class P0
  • Radial Clearance Trade No CN
  • Ring Material Stainless Steel
  • Ball Material Stainless Steel
  • Cage Material Stainless Steel
  • Dynamic Radial Load 344 lbf
  • Static Radial Load 132 lbf
  • Temperature Range -30° to 120 °C
  • Lubrication Grease
  • RoHS Compliant
  • REACH Compliant
  • Max Speed 24000 rpm
  • Weight 0.0076 kg
  • Price（$） 2.91
Stainless Steel Deep Groove Ball Bearings W 626-2RS1 dimension drawing
Download DWG Download PDF

Features

Why Choose W 626-2RS1 Bearing for Precision Tasks?

W 626-2RS1 Bearing is crafted with stainless steel rings and balls, ensuring corrosion resistance and durability.
Its sealed design protects against dust and moisture, making it suitable for various environments.

The bearing handles dynamic radial loads up to 344 lbf, providing reliable performance in precision applications.
With a maximum speed of 24,000 rpm, it offers smooth operation for high-speed tasks.

W 626-2RS1 Bearing’s compact size (6 mm×19 mm×6 mm) makes it ideal for space-constrained installations.
Its grease lubrication reduces maintenance needs, ensuring long-term efficiency.

Application

Practical Applications of W 626-2RS1 Bearing
W 626-2RS1 Bearing is commonly used in small electric motors, such as those found in household appliances like fans or blenders. Its sealed design keeps out dust and moisture, ensuring long-lasting performance in everyday devices.

How Does W 626-2RS1 Bearing Improve Performance?
In automation systems, W 626-2RS1 Bearing helps reduce friction in robotic arms, allowing for smoother and more precise movements. The stainless steel construction also resists corrosion, making it suitable for humid or washdown environments.

Built for Versatility: W 626-2RS1 Bearing
This bearing works well in medical devices like dental tools, where its compact size and reliable sealing are essential. The grease lubrication ensures quiet operation, which is important in sensitive clinical settings.

Light-Duty vs Heavy-Duty: Best Uses for W 626-2RS1 Bearing
While W 626-2RS1 Bearing excels in light-duty applications like printers, it can also handle moderate loads in industrial sensors. Its balanced design offers a good mix of durability and efficiency for various tasks.
