Thin Section Ball Bearings S63801

Thin Section Ball Bearings S63801

The S63801 is a slim radial ball bearing measuring 12mm by 21mm by 7mm, crafted entirely from stainless steel for durability. It supports radial loads up to 388 lbf and can spin at speeds up to 32,400 RPM, making it suitable for fast-moving applications.

With an open design and ABEC-1 precision, it offers smooth operation while requiring regular lubrication. The bearing works in a wide temperature range from -86°F to 230°F.

Its compact size and lightweight construction (just 8.5g) make it ideal for precision instruments or small machinery. Compliant with RoHS and REACH standards, it’s a reliable choice for various industrial uses.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number S63801
  • Brand TFL
  • Bore Dia 12 mm
  • Bore Dia Tolerance -0.008mm to 0
  • Outer Dia 21 mm
  • Outer Dia Tolerance -0.009mm to 0
  • Width 7 mm
  • Width Tolerance -0.120mm to 0
  • Radial Clearance 0.003mm to 0.018mm
  • System of Measurement Metric
  • Bearing Type Ball
  • For Load Direction Radial
  • Construction Single Row
  • Seal Type Open
  • Tolerance Class ABEC-1
  • Radial Clearance Trade No C0
  • Ring Material Stainless Steel
  • Ball Material Stainless Steel
  • Cage Material Stainless Steel
  • Dynamic Radial Load 388 lbf
  • Static Radial Load 210 lbf
  • Temperature Range -86 to 230 °F
  • Lubrication Required
  • RoHS Compliant
  • REACH Compliant
  • Max Speed 32400 rpm
  • Weight 8.5 g
  • Price（$） 1.8
Thin Section Ball Bearings S63801 dimension drawing
Download DWG Download PDF

Features

Performance Features of S63801 Bearing

S63801 Bearing is crafted with stainless steel rings and balls, offering reliable radial load support.
Its dynamic radial load capacity reaches 388 lbf, making it suitable for various applications.

The ABEC-1 tolerance class ensures consistent performance, while the C0 radial clearance provides smooth operation.
With a maximum speed of 32,400 rpm, it balances efficiency and durability.

S63801 Bearing operates in temperatures from -86 to 230°F, adapting to diverse environments.
Its compact size of 12 mm×21 mm×7 mm makes it ideal for space-constrained designs.

The stainless steel cage maintains ball alignment, reducing wear and extending service life.
Regular lubrication ensures optimal performance and longevity.

Application

Common Applications of S63801 Bearing
S63801 Bearing is widely used in industrial equipment like small conveyor systems and packaging machines, where its compact size and radial load capacity are beneficial. The stainless steel construction ensures durability in various working conditions.

In automotive applications, S63801 Bearing fits well in components such as electric window mechanisms and small gearboxes. Its lightweight design and high-speed capability make it a reliable choice for vehicle systems.

For medical devices, S63801 Bearing is ideal for precision instruments like dental drills and lab equipment. The open design allows for easy lubrication, maintaining smooth operation over time.

Automation and robotics benefit from S63801 Bearing in robotic arms and small actuators, where its low friction and high-speed performance are crucial. The ABEC-1 tolerance ensures consistent movement in automated processes.

In consumer electronics, S63801 Bearing can be found in devices like printers and small cooling fans. Its stainless steel material resists corrosion, making it suitable for long-term use in household appliances.
