Thin Section Ball Bearings S6900zz

Thin Section Ball Bearings S6900zz

The S6900zz is a slim ball bearing with a 10mm bore and 22mm outer diameter, measuring just 6mm wide. Made entirely from stainless steel, it offers good resistance to corrosion and wear.

This shielded bearing handles radial loads up to 546 lbf and can spin at high speeds up to 27,900 RPM. Its ABEC-1 precision ensures smooth operation for most general applications.

The compact design makes it ideal for space-constrained uses like small motors or medical equipment. It requires lubrication and works in temperatures from -30°C to 110°C.

Weighing only 10 grams, it’s a lightweight solution for precision instruments. Compliant with RoHS and REACH standards, it’s a reliable choice for various industries.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number S6900zz
  • Brand TFL
  • Bore Dia 10 mm
  • Bore Dia Tolerance -0.008mm to 0
  • Outer Dia 22 mm
  • Outer Dia Tolerance -0.009mm to 0
  • Width 6 mm
  • Width Tolerance -0.120mm to 0
  • Radial Clearance 0.003mm to 0.018mm
  • System of Measurement Metric
  • Bearing Type Ball
  • For Load Direction Radial
  • Construction Single Row
  • Seal Type Shielded
  • Tolerance Class ABEC-1
  • Radial Clearance Trade No C0
  • Ring Material Stainless Steel
  • Ball Material Stainless Steel
  • Cage Material Stainless Steel
  • Dynamic Radial Load 546 lbf
  • Static Radial Load 257 lbf
  • Temperature Range -86 to 230 °F
  • Lubrication Required
  • RoHS Compliant
  • REACH Compliant
  • Max Speed 27900 rpm
  • Weight 10 g
  • Price（$） 2
Thin Section Ball Bearings S6900zz dimension drawing
Download DWG Download PDF

Features

How Does S6900zz Bearing Reduce Friction?

S6900zz Bearing features stainless steel rings and balls, ensuring smooth operation with minimal friction.
Its shielded design helps retain lubrication, further reducing wear and improving efficiency.

The ABEC-1 tolerance class ensures consistent performance, making it suitable for precision applications.
With a maximum speed of 27,900 rpm, it delivers reliable performance in high-speed scenarios.

S6900zz Bearing’s compact 10 mm×22 mm×6 mm size makes it ideal for space-constrained installations.
The stainless steel construction also provides good resistance to corrosion in various environments.

Application

Common Applications of S6900zz Bearing
S6900zz Bearing is widely used in industrial automation, particularly in robotic arms and precision machinery, where its thin section design saves space without compromising performance. The shielded seals help keep contaminants out, extending service life in dusty environments.

In the automotive sector, S6900zz Bearing fits well in compact electric motors and gear mechanisms, thanks to its lightweight stainless steel construction. Its ABEC-1 tolerance ensures smooth rotation, even in high-speed applications.

For medical devices like portable diagnostic tools, S6900zz Bearing offers reliable performance with minimal maintenance. The stainless steel materials resist corrosion, making it suitable for sterilisation processes.

In consumer electronics, S6900zz Bearing is often found in small fans and printers, where quiet operation is essential. Its low-profile design integrates seamlessly into tight spaces.
