Thin Section Ball Bearings 6806zz

Thin Section Ball Bearings 6806zz

The 6806zz is a slim, shielded ball bearing measuring 30mm by 42mm by 7mm, crafted from chrome steel for durability. It handles radial loads up to 1021 lbf and spins smoothly at speeds up to 18,000 RPM.

Its stainless steel cage and shielded design help keep dirt out while maintaining performance. The bearing operates well in temperatures from -30°C to 110°C and requires regular lubrication.

With a compact width of just 7mm, it fits neatly into tight spaces. Ideal for applications like small motors or precision instruments where space is limited.

Weighing only 27g, it’s lightweight yet sturdy. Compliant with RoHS and REACH standards for safe use.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number 6806zz
  • Brand TFL
  • Bore Dia 30 mm
  • Bore Dia Tolerance -0.01mm to 0
  • Outer Dia 42 mm
  • Outer Dia Tolerance -0.011mm to 0
  • Width 7 mm
  • Width Tolerance -0.120mm to 0
  • Radial Clearance 0.006mm to 0.020mm
  • System of Measurement Metric
  • Bearing Type Ball
  • For Load Direction Radial
  • Construction Single Row
  • Seal Type Shielded
  • Tolerance Class ABEC-1
  • Radial Clearance Trade No C0
  • Ring Material Chrome Steel
  • Ball Material Chrome Steel
  • Cage Material Stainless Steel
  • Dynamic Radial Load 1021 lbf
  • Static Radial Load 765 lbf
  • Temperature Range -30°C to 110 °C
  • Lubrication Required
  • RoHS Compliant
  • REACH Compliant
  • Max Speed 18000 rpm
  • Weight 27 g
  • Price（$） 2
Thin Section Ball Bearings 6806zz dimension drawing
Download DWG Download PDF

Features

Performance Features of 6806zz Bearing

6806zz Bearing features a compact design with dimensions of 30 mm×42 mm×7 mm, ideal for space-constrained applications.
Its shielded construction protects against contaminants while maintaining smooth operation.

The chrome steel rings and balls ensure durability, supporting dynamic radial loads up to 1021 lbf.
With a maximum speed of 18,000 rpm, it delivers reliable performance in high-speed scenarios.

The ABEC-1 tolerance and C0 radial clearance provide consistent precision for radial load applications.
Its temperature range of -30°C to 110°C makes it suitable for various operating conditions.

Application

Common Applications of 6806zz Bearing
In industrial settings, 6806zz Bearing is commonly used in compact machinery like packaging equipment and small conveyors, where its thin section design saves space without sacrificing performance. The shielded seals help keep contaminants out, extending the bearing’s lifespan.

Where Is 6806zz Bearing Used?
You’ll often find 6806zz Bearing in automotive applications such as electric window mechanisms or small gearboxes, thanks to its reliable radial load handling. Its lightweight construction also makes it a good fit for portable tools and devices.

Ideal for Precision: 6806zz Bearing
For medical devices like dental handpieces or lab instruments, 6806zz Bearing offers smooth rotation and consistent accuracy. The chrome steel construction ensures durability even in high-speed, low-tolerance environments.

Automotive vs Industrial: Applications of 6806zz Bearing
In cars, 6806zz Bearing works well in auxiliary systems like fans or pumps, while in factories, it’s suited for light-duty robotic arms. Its versatility stems from the balanced load capacity and moderate speed tolerance.

Perfect Fit for Automation: 6806zz Bearing
6806zz Bearing is a go-to choice for 3D printers and small robotic joints, where its slim profile and shielded design reduce maintenance needs. The ABEC-1 tolerance provides enough precision for most automated tasks.
