Thin Section Ball Bearings 6703 2rs

Thin Section Ball Bearings 6703 2rs

The 6703 2RS is a compact thin-section ball bearing with a 17mm bore and 23mm outer diameter, measuring just 4mm wide. Made from chrome steel, it’s designed for radial loads up to 225 lbf and can spin at speeds up to 11,000 RPM.

Its sealed design keeps dirt out and grease in, making it low-maintenance. The stainless steel cage adds durability, while the ABEC-1 tolerance ensures smooth operation.

This bearing works in temperatures from -30°C to 110°C, suitable for small machinery or precision instruments. Weighing only 4g, it’s lightweight yet sturdy.

Compliant with RoHS and REACH standards, it’s a reliable choice for applications needing a slim, sealed bearing. Ideal for compact spaces where performance matters.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number 6703 2rs
  • Brand TFL
  • Bore Dia 17 mm
  • Bore Dia Tolerance -0.008mm to 0
  • Outer Dia 23 mm
  • Outer Dia Tolerance -0.009mm to 0
  • Width 4 mm
  • Width Tolerance -0.120mm to 0
  • Radial Clearance 0.003mm to 0.018mm
  • System of Measurement Metric
  • Bearing Type Ball
  • For Load Direction Radial
  • Construction Single Row
  • Seal Type Sealed
  • Tolerance Class ABEC-1
  • Radial Clearance Trade No C0
  • Ring Material Chrome Steel
  • Ball Material Chrome Steel
  • Cage Material Stainless Steel
  • Dynamic Radial Load 225 lbf
  • Static Radial Load 148 lbf
  • Temperature Range -30°C to 110 °C
  • Lubrication Required
  • RoHS Compliant
  • REACH Compliant
  • Max Speed 11000 rpm
  • Weight 4 g
  • Price（$） 1.5
Thin Section Ball Bearings 6703 2rs dimension drawing
Download DWG Download PDF

Features

How Does 6703 2rs Bearing Reduce Friction?

6703 2rs Bearing features a sealed design with chrome steel rings and balls, ensuring smooth radial movement.
Its ABEC-1 tolerance class provides consistent performance, reducing friction during operation.
The stainless steel cage maintains ball alignment, enhancing efficiency and minimising wear.
With a maximum speed of 11,000 rpm, it delivers reliable performance in compact applications.

Application

Common Applications of 6703 2rs Bearing
6703 2rs Bearing is widely used in industrial automation, particularly in compact machinery where space is limited. Its sealed design helps keep out dust and debris, ensuring smooth operation in challenging environments.

In automotive applications, 6703 2rs Bearing fits well in small electric motors and gear mechanisms. The chrome steel construction provides durability, while the thin section design saves valuable space.

For medical devices, 6703 2rs Bearing offers reliable performance in precision instruments like surgical tools. The ABEC-1 tolerance ensures consistent movement, which is essential for accurate medical procedures.

In consumer electronics, 6703 2rs Bearing is often found in devices like printers and small fans. Its lightweight design and sealed construction make it a practical choice for everyday use.
