Single Row Angular Contact Ball Bearings (General) 7206 BEGBP

Brand: TFL Bearing Interchangeable: SKF 7206 BEGBP 30 mm × 62 mm × 16 mm Metric Open
Part number: 7206 BEGBP
Single Row Angular Contact Ball Bearings (General) 7206 BEGBP
In Stock
US$16.24 / piece
Reference price · volume pricing on request
Get a Quote WhatsApp
  • ISO 9001 quality system
  • RoHS & REACH compliant
  • Pre-shipment inspection
  • Lead time confirmed with your quote
Dimensions
Bore Dia30 mm
Bore Dia Tolerance-0.008mm to 0
Outer Dia62 mm
Outer Dia Tolerance-0.011mm to 0
Width16 mm
Width Tolerance-0.05mm to 0
External Diameter On Inner Ring (Large Side Face)42.65 mm
External Diameter On Inner Ring (Small Side Face)36.13 mm
Internal Diameter On Outer Ring50.1 mm
Chamfer Dimension1 mm
Performance
Dynamic Radial Load5,400 lbf
Static Radial Load3,510 lbf
Temperature Range-30° to 110 °C
Max Speed14,000 rpm
Characteristics
System of MeasurementMetric
Bearing TypeBall
Contact Angle40°
For Load DirectionAngular Contact
ConstructionSingle Row
Seal TypeOpen
Distance Pressure Point (a)27.3 mm
LubricationLubricated
Tolerance ClassP6 (ABEC-3)
Weight0.2 kg
Material
Ring MaterialChrome Steel
Ball MaterialChrome Steel
Cage MaterialNylon
Compliance
ROHSCompliant
REACHCompliant
Dimension drawing · click to enlarge

Description

The 7206 BEGBP is a single-row angular contact ball bearing with a 30mm bore and 62mm outer diameter, crafted from sturdy chrome steel. It handles radial loads up to 5400 lbf and spins smoothly at speeds up to 14,000 RPM.

Its 40° contact angle efficiently manages combined loads, while the nylon cage reduces friction for quieter operation. The open design allows easy lubrication and maintenance.

This bearing suits applications like pumps or gearboxes where angular loads are present. It works well in temperatures from -30°C to 110°C and meets P6 precision standards.

Weighing just 0.2kg, it’s a lightweight yet durable choice. Compliant with RoHS and REACH, it’s interchangeable with SKF bearings for easy replacement.

Features

Why Choose 7206 BEGBP Bearing for Precision Tasks?

7206 BEGBP Bearing features a 40° contact angle, ideal for handling combined radial and axial loads with precision.
Its chrome steel rings and balls ensure durability, while the nylon cage reduces friction and noise.

With a dynamic radial load capacity of 5400 lbf, it performs reliably in high-speed applications.
The P6 tolerance class guarantees consistent accuracy, making it suitable for demanding machinery.

Operating smoothly at speeds up to 14,000 rpm, it balances performance and longevity.
Its open design allows for easy lubrication, maintaining efficiency across a wide temperature range.

Application

Industrial Uses of 7206 BEGBP Bearing
7206 BEGBP Bearing is commonly used in machine tools, where its 40° contact angle efficiently handles combined radial and axial loads. The open design and nylon cage make it suitable for high-speed operations up to 14,000 rpm.

In automotive applications, 7206 BEGBP Bearing supports gearboxes and wheel hubs, ensuring smooth performance under angular loads. Its metric sizing and P6 tolerance class provide precise fitment for European and Asian vehicles.

For automation systems, 7206 BEGBP Bearing excels in robotic arms and conveyor belts, thanks to its durable chrome steel construction. The lubricated design reduces friction, extending service life in continuous operation.

Where Is 7206 BEGBP Bearing Used?
You’ll find 7206 BEGBP Bearing in industrial fans, where its high-speed capability and load handling are essential. The nylon cage also helps reduce noise, making it ideal for quieter environments.

In medical imaging devices, 7206 BEGBP Bearing offers reliable performance due to its precise P6 tolerance. The chrome steel rings ensure long-term durability in critical healthcare equipment.

Built for Heavy-Duty Use: 7206 BEGBP Bearing
7206 BEGBP Bearing is a go-to for construction equipment, handling heavy loads with ease. Its robust design and temperature range (-30° to 110°C) suit harsh outdoor conditions.

In 3D printers, 7206 BEGBP Bearing provides smooth linear motion, thanks to its angular contact design. The lightweight nylon cage also helps maintain precision in delicate printing tasks.

Automotive vs Aerospace: Applications of 7206 BEGBP Bearing
In cars, 7206 BEGBP Bearing is often used in transmissions, balancing speed and load capacity. For aircraft, its P6 tolerance ensures reliability in avionics and control systems.

For home appliances like washing machines, 7206 BEGBP Bearing reduces vibration and noise. The lubricated construction ensures quiet operation, even during high-speed spins.
