Thin Section Ball Bearings 6701 2rs

Thin Section Ball Bearings 6701 2rs

The 6701 2RS is a compact thin-section ball bearing, measuring 12mm by 18mm by 4mm, crafted from durable chrome steel. It handles radial loads up to 209 lbf and spins smoothly at speeds up to 15,000 RPM.

Its sealed design keeps dirt out and lubrication in, making it low-maintenance. The stainless steel cage adds durability, while the ABEC-1 tolerance ensures reliable performance.

This bearing works well in temperatures from -30°C to 110°C, suitable for small machinery or precision instruments. Its lightweight design, at just 3.1g, makes it easy to handle.

Compliant with RoHS and REACH standards, it’s a safe and practical choice for various applications. Ideal for devices where space is limited but performance is key.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number 6701 2rs
  • Brand TFL
  • Bore Dia 12 mm
  • Bore Dia Tolerance -0.008mm to 0
  • Outer Dia 18 mm
  • Outer Dia Tolerance -0.008mm to 0
  • Width 4 mm
  • Width Tolerance -0.120mm to 0
  • Radial Clearance 0.003mm to 0.018mm
  • System of Measurement Metric
  • Bearing Type Ball
  • For Load Direction Radial
  • Construction Single Row
  • Seal Type Sealed
  • Tolerance Class ABEC-1
  • Radial Clearance Trade No C0
  • Ring Material Chrome Steel
  • Ball Material Chrome Steel
  • Cage Material Stainless Steel
  • Dynamic Radial Load 209 lbf
  • Static Radial Load 120 lbf
  • Temperature Range -30°C to 110 °C
  • Lubrication Required
  • RoHS Compliant
  • REACH Compliant
  • Max Speed 15000 rpm
  • Weight 3.1 g
  • Price（$） 1
Thin Section Ball Bearings 6701 2rs dimension drawing
Download DWG Download PDF

Features

How Does 6701 2rs Bearing Reduce Friction?

6701 2rs Bearing features chrome steel rings and balls, ensuring smooth operation with minimal friction.
Its sealed design helps retain lubrication, further reducing wear and maintenance needs.
The ABEC-1 tolerance class ensures consistent performance, making it suitable for precision applications.
With a maximum speed of 15,000 rpm, it delivers reliable efficiency in compact spaces.

Built for Reliability: 6701 2rs Bearing

6701 2rs Bearing is constructed with chrome steel components, offering durability and resistance to wear.
The sealed design protects against contaminants, extending its service life in various environments.
Its compact size of 12 mm×18 mm×4 mm makes it ideal for applications with limited space.
The bearing maintains performance within a temperature range of -30°C to 110°C.

Why Choose 6701 2rs Bearing for Precision Tasks?

6701 2rs Bearing’s ABEC-1 tolerance ensures precise operation, crucial for delicate instruments.
The stainless steel cage keeps the balls aligned, reducing noise and vibration.
Its dynamic radial load capacity of 209 lbf provides reliable support in radial applications.
The sealed design also helps maintain lubrication, ensuring consistent performance over time.

Application

Common Applications of 6701 2rs Bearing
The 6701 2rs Bearing is widely used in small industrial equipment, such as miniature motors and precision instruments, where its compact size and sealed design are beneficial. Its chrome steel construction ensures durability in demanding environments.

In automotive applications, 6701 2rs Bearing fits well in components like electric window mechanisms and small gearboxes. The sealed design helps keep contaminants out, extending the bearing’s service life.

For medical devices, 6701 2rs Bearing provides reliable performance in tools like dental handpieces and diagnostic equipment. Its low friction and smooth operation are key for precision tasks.

In consumer electronics, 6701 2rs Bearing is often found in devices like cooling fans and small printers. The lightweight design and efficient performance make it a popular choice for compact gadgets.
