Stainless Steel Deep Groove Ball Bearings WBB1-8708-2RS1

Stainless Steel Deep Groove Ball Bearings WBB1-8708-2RS1

The WBB1-8708-2RS1 is a compact stainless steel deep groove ball bearing, measuring 8mm by 14mm by 4mm. Its sealed design keeps out dirt and moisture, making it low-maintenance.

With a dynamic radial load capacity of 104 lbf, it handles moderate loads smoothly. It spins efficiently at speeds up to 28,000 RPM, suitable for fast-moving applications.

The all-stainless steel construction resists corrosion, ideal for damp or harsh environments. Its grease lubrication ensures quiet operation and long service life.

This bearing fits well in small machinery, dental tools, or precision instruments where reliability matters. It’s interchangeable with SKF models for easy replacement. Compliant with RoHS and REACH standards.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number WBB1-8708-2RS1
  • Brand TFL
  • Interchangeable SKF
  • Bore Dia 8 mm
  • Bore Dia Tolerance -0.008mm to 0
  • Outer Dia 14 mm
  • Outer Dia Tolerance -0.008mm to 0
  • Width 4 mm
  • Width Tolerance -0.12mm to 0
  • System of Measurement Metric
  • Bearing Type Ball
  • For Load Direction Radial
  • Construction Single Row
  • Seal Type Sealed
  • Tolerance Class P0
  • Radial Clearance Trade No CN
  • Ring Material Stainless Steel
  • Ball Material Stainless Steel
  • Cage Material Stainless Steel
  • Dynamic Radial Load 104 lbf
  • Static Radial Load 43 lbf
  • Temperature Range -30° to 120 °C
  • Lubrication Grease
  • RoHS Compliant
  • REACH Compliant
  • Max Speed 28000 rpm
  • Weight 0.002 kg
Stainless Steel Deep Groove Ball Bearings WBB1-8708-2RS1 dimension drawing
Download DWG Download PDF

Features

How Does WBB1-8708-2RS1 Bearing Reduce Friction?

WBB1-8708-2RS1 Bearing features stainless steel construction, ensuring smooth operation with minimal friction.
Its sealed design retains grease lubrication, reducing wear and maintenance needs.

The single-row deep groove design allows efficient radial load handling up to 104 lbf.
With a maximum speed of 28,000 rpm, it delivers reliable performance in various applications.

WBB1-8708-2RS1 Bearing operates in temperatures from -30° to 120°C, suitable for diverse environments.
Its compact size (8 mm×14 mm×4 mm) makes it ideal for space-constrained installations.

Application

Practical Applications of WBB1-8708-2RS1 Bearing
WBB1-8708-2RS1 Bearing works well in small industrial equipment, like compact pumps or electric motors, where its sealed design keeps out dust and moisture. The stainless steel construction also makes it suitable for environments where corrosion resistance matters.

In automotive applications, WBB1-8708-2RS1 Bearing fits neatly into components like window regulators or small gear mechanisms. Its compact size and radial load capacity ensure smooth operation without taking up much space.

For medical devices, WBB1-8708-2RS1 Bearing is a reliable choice for precision instruments like dental tools or lab equipment. The grease lubrication helps maintain quiet and consistent performance over time.

Around the home, WBB1-8708-2RS1 Bearing can be found in appliances like cooling fans or small power tools. Its durability and low maintenance make it a handy option for everyday devices.
