Stainless Steel Deep Groove Ball Bearings W 6207-2Z

The W 6207-2Z is a stainless steel deep groove ball bearing with a 35mm bore and 72mm outer diameter, designed for radial loads. It handles dynamic loads up to 4968 lbf and operates smoothly at speeds up to 11000 RPM.

Shielded on both sides, it keeps grease in and dirt out, making it low-maintenance. The all-stainless construction ensures corrosion resistance and durability in harsh conditions.

With a temperature range of -30°C to 120°C, it’s suitable for various environments. The bearing is interchangeable with SKF models, offering a reliable replacement option.

Ideal for applications like food processing or marine equipment where moisture resistance is key. Weighing 0.28kg, it’s a sturdy choice for its size, compliant with RoHS and REACH standards.

Get A Free Quote

Description

Features

Application

Q&A

Product Parameters

Part Number W 6207-2Z
Brand TFL
Interchangeable SKF
Bore Dia 35 mm
Bore Dia Tolerance -0.012mm to 0
Outer Dia 72 mm
Outer Dia Tolerance -0.013mm to 0
Width 17 mm
Width Tolerance -0.12mm to 0
System of Measurement Metric
Bearing Type Ball
For Load Direction Radial
Construction Single Row
Seal Type Shielded
Tolerance Class P0
Radial Clearance Trade No CN
Ring Material Stainless Steel
Ball Material Stainless Steel
Cage Material Stainless Steel
Dynamic Radial Load 4968 lbf
Static Radial Load 3440 lbf
Temperature Range -30° to 120 °C
Lubrication Grease
RoHS Compliant
REACH Compliant
Max Speed 11000 rpm
Weight 0.28 kg

Stainless Steel Deep Groove Ball Bearings W 6207-2Z dimension drawing

Download DWG Download PDF

Features

Why Choose W 6207-2Z Bearing for Precision Tasks?

W 6207-2Z Bearing is crafted with stainless steel rings and balls, ensuring corrosion resistance and durability.

Its shielded design protects against contaminants, making it ideal for precision applications.

With a dynamic radial load capacity of 4968 lbf, it handles demanding radial loads efficiently.

The bearing operates smoothly at speeds up to 11,000 rpm, balancing performance and longevity.

Application

Industrial Uses of W 6207-2Z Bearing
W 6207-2Z Bearing is commonly used in conveyor systems and pumps, where its shielded design helps keep contaminants out. The stainless steel construction makes it suitable for environments with exposure to moisture or chemicals.

In automotive applications, W 6207-2Z Bearing fits well in electric motors and gearboxes, providing reliable radial load support. Its grease lubrication ensures smooth operation even under continuous use.

For household appliances like washing machines, W 6207-2Z Bearing offers quiet and efficient performance. The metric dimensions make it easy to replace in a variety of European and Asian models.

Where Is W 6207-2Z Bearing Used?
You’ll often find W 6207-2Z Bearing in industrial fans, where its high-speed capability and durability are key. The shielded seals help extend its lifespan by reducing dust ingress.

In robotics, W 6207-2Z Bearing is a popular choice for joint mechanisms due to its smooth rotation. The stainless steel material also resists corrosion in humid or washdown environments.

Designed for Versatility: W 6207-2Z Bearing
W 6207-2Z Bearing works well in food processing equipment, thanks to its stainless steel build meeting hygiene standards. The grease lubrication ensures low maintenance in high-use settings.

For small machinery like printers, W 6207-2Z Bearing provides precise radial support. Its compact size and shielded design make it a practical fit for tight spaces.
