Stainless Steel Deep Groove Ball Bearings W 61906-2RS1/VT378

Stainless Steel Deep Groove Ball Bearings W 61906-2RS1/VT378

The W 61906-2RS1/VT378 is a compact stainless steel deep groove ball bearing, measuring 30mm by 47mm by 9mm. Its sealed design keeps out dirt and moisture, making it low-maintenance for everyday use.

This bearing handles radial loads up to 1403 lbf and spins smoothly at speeds up to 19,000 RPM. The stainless steel construction resists corrosion, ideal for damp or demanding environments.

Its single-row design and ABEC 1 tolerance ensure reliable performance in light to moderate applications. The chrome steel cage adds durability without adding much weight (just 0.043kg).

Suitable for small machinery, electric motors, or food processing equipment where hygiene matters. Interchangeable with SKF bearings for easy replacements. Works in temperatures from -30°C to 120°C.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number W 61906-2RS1/VT378
  • Brand TFL
  • Interchangeable SKF
  • Bore Dia 30 mm
  • Bore Dia Tolerance -0.01mm to 0
  • Outer Dia 47 mm
  • Outer Dia Tolerance -0.011mm to 0
  • Width 9 mm
  • Width Tolerance -0.12mm to 0
  • System of Measurement Metric
  • Bearing Type Ball
  • For Load Direction Radial
  • Construction Single Row
  • Seal Type Sealed
  • Tolerance Class ABEC 1 | ISO P0
  • Radial Clearance Trade No CN
  • Ring Material Stainless Steel
  • Ball Material Stainless Steel
  • Cage Material Chrome Steel
  • Dynamic Radial Load 1403 lbf
  • Static Radial Load 1124 lbf
  • Temperature Range -30°to 120 °C
  • REACH Compliant
  • Max Speed 19000 rpm
  • Weight 0.043 kg
Stainless Steel Deep Groove Ball Bearings W 61906-2RS1/VT378 dimension drawing
Download DWG Download PDF

Features

How Does W 61906-2RS1/VT378 Bearing Reduce Friction?

W 61906-2RS1/VT378 Bearing features stainless steel rings and balls, ensuring smooth operation with minimal friction.

The sealed design keeps contaminants out, maintaining consistent performance over time.

With a dynamic radial load capacity of 1403 lbf, it handles demanding radial loads efficiently.

Its maximum speed of 19,000 rpm makes it suitable for high-speed applications.

Application

Industrial Uses of W 61906-2RS1/VT378 Bearing
W 61906-2RS1/VT378 Bearing is commonly used in conveyor systems and packaging machines, where its sealed design keeps contaminants out. The stainless steel construction ensures it handles moderate radial loads efficiently.

What Makes W 61906-2RS1/VT378 Bearing a Preferred Choice?
In automotive applications like electric motors, W 61906-2RS1/VT378 Bearing offers reliable performance due to its corrosion-resistant materials. Its compact size fits well in tight spaces without compromising durability.

Perfect Fit for Automation: W 61906-2RS1/VT378 Bearing
W 61906-2RS1/VT378 Bearing works smoothly in robotic arms and 3D printers, thanks to its low-friction design. The sealed feature also makes it suitable for dusty or humid environments.

Medical vs Industrial: Where W 61906-2RS1/VT378 Bearing Excels
W 61906-2RS1/VT378 Bearing is ideal for medical devices like lab equipment, where hygiene matters. In industrial settings, it’s a go-to for food processing machinery due to its stainless steel build.
