Stainless Steel Deep Groove Ball Bearings W 61700 X-2RS1

Stainless Steel Deep Groove Ball Bearings W 61700 X-2RS1

The W 61700 X-2RS1 is a compact stainless steel deep groove ball bearing, measuring 10mm by 15mm by 4mm. It handles radial loads up to 110 lbf and spins smoothly at speeds up to 24,000 RPM.

Its sealed design keeps grease in and dirt out, making it low-maintenance. The all-stainless construction ensures corrosion resistance and durability.

This bearing works well in temperatures from -30°C to 120°C, suitable for various environments. It’s interchangeable with SKF models for easy replacement.

Ideal for small machinery or instruments where space is limited. Compliant with RoHS and REACH standards, it’s a reliable choice for many applications.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number W 61700 X-2RS1
  • Brand TFL
  • Interchangeable SKF
  • Bore Dia 10 mm
  • Bore Dia Tolerance -0.008mm to 0
  • Outer Dia 15 mm
  • Outer Dia Tolerance -0.008mm to 0
  • Width 4 mm
  • Width Tolerance -0.12mm to 0
  • System of Measurement Metric
  • Bearing Type Ball
  • For Load Direction Radial
  • Construction Single Row
  • Seal Type Sealed
  • Tolerance Class P0
  • Radial Clearance Trade No CN
  • Ring Material Stainless Steel
  • Ball Material Stainless Steel
  • Cage Material Stainless Steel
  • Dynamic Radial Load 110 lbf
  • Static Radial Load 49 lbf
  • Temperature Range -30° to 120 °C
  • Lubrication Grease
  • RoHS Compliant
  • REACH Compliant
  • Max Speed 24000 rpm
  • Weight 0.0018 kg
Stainless Steel Deep Groove Ball Bearings W 61700 X-2RS1 dimension drawing
Download DWG Download PDF

Features

Why Choose W 61700 X-2RS1 Bearing for Precision Tasks?

W 61700 X-2RS1 Bearing is crafted with stainless steel rings and balls, offering excellent resistance to corrosion.

Its compact size of 10 mm×15 mm×4 mm makes it ideal for applications where space is limited.

The sealed design ensures long-lasting lubrication, reducing the need for frequent maintenance.

With a maximum speed of 24,000 rpm, it delivers smooth and reliable performance in precision instruments.

Application

Industrial Uses of W 61700 X-2RS1 Bearing
W 61700 X-2RS1 Bearing is commonly used in small industrial machinery, such as compact pumps and electric motors, where its sealed design keeps contaminants out. The stainless steel construction ensures durability in humid or corrosive environments.

How Does W 61700 X-2RS1 Bearing Improve Performance?
In automotive applications like small gearboxes or actuators, W 61700 X-2RS1 Bearing provides smooth radial load support with minimal maintenance. Its compact size and metric dimensions make it a versatile fit for various European and Asian vehicle components.

Perfect Fit for Automation: W 61700 X-2RS1 Bearing
W 61700 X-2RS1 Bearing works well in robotic arms and precision instruments, where its low friction and sealed design enhance reliability. The grease lubrication ensures quiet operation, ideal for sensitive environments.

Medical vs Industrial: Where W 61700 X-2RS1 Bearing Excels
W 61700 X-2RS1 Bearing is suitable for medical devices like dental tools, offering corrosion resistance and hygiene. In industrial settings, it handles light loads in conveyor systems or small fans with consistent performance.

Essential Roles of W 61700 X-2RS1 Bearing
For household appliances like electric shavers or small fans, W 61700 X-2RS1 Bearing delivers quiet and efficient operation. The sealed design prevents dust ingress, extending the bearing’s lifespan in everyday use.
