Stainless Steel Deep Groove Ball Bearings D/W R2

Stainless Steel Deep Groove Ball Bearings D/W R2

The D/W R2 is a compact stainless steel deep groove ball bearing, measuring just 0.125″ by 0.375″ by 0.15618″. Its open design and single-row construction make it simple to install and maintain.

This bearing handles radial loads up to 80 lbf and spins smoothly at speeds up to 85,000 RPM. It performs reliably in temperatures ranging from -30°C to 120°C.

Made entirely from stainless steel, it resists corrosion and lasts longer in demanding environments. The bearing is interchangeable with SKF models, offering a convenient replacement option.

Ideal for small machinery or instruments where space is limited but performance matters. Weighing only 0.0012kg, it’s lightweight yet durable. Compliant with RoHS and REACH standards for safe use.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number D/W R2
  • Brand TFL
  • Interchangeable SKF
  • Bore Dia 0.125"
  • Bore Dia Tolerance -0.00019" to 0.00019"
  • Outer Dia 0.375"
  • Outer Dia Tolerance -0.0007" to -0.00031"
  • Width 0.15618"
  • Width Tolerance -0.005" to 0"
  • System of Measurement Inch
  • Bearing Type Ball
  • For Load Direction Radial
  • Construction Single Row
  • Seal Type Open
  • Tolerance Class P0
  • Radial Clearance Trade No CN
  • Ring Material Stainless Steel
  • Ball Material Stainless Steel
  • Cage Material Stainless Steel
  • Dynamic Radial Load 80 lbf
  • Static Radial Load 25 lbf
  • Temperature Range -30° to 120 °C
  • RoHS Compliant
  • REACH Compliant
  • Max Speed 85000 rpm
  • Weight 0.0012 kg
Stainless Steel Deep Groove Ball Bearings D/W R2 dimension drawing
Download DWG Download PDF

Features

Why Choose D/W R2 Bearing for Precision Tasks?

D/W R2 Bearing is crafted from stainless steel, offering excellent resistance to corrosion and wear.
Its compact size of 0.125″×0.375″×0.15618″ makes it ideal for precision applications where space is limited.

The open design ensures easy installation and maintenance, saving time and effort.
With a dynamic radial load capacity of 80 lbf, it handles demanding radial loads reliably.

D/W R2 Bearing operates smoothly at speeds up to 85,000 rpm, balancing performance and durability.
Its stainless steel construction ensures long service life, even in challenging environments.

Application

Where Is D/W R2 Bearing Used?
D/W R2 Bearing is commonly found in small industrial equipment, such as precision instruments and miniature motors, where its stainless steel construction offers good corrosion resistance. The open design allows for easy lubrication, making it suitable for various environments.

In automotive applications, D/W R2 Bearing can be used in small electric motors or sensors, providing reliable radial load support. Its inch sizing makes it compatible with many American and British vehicle components.

For medical devices, D/W R2 Bearing’s stainless steel material ensures hygiene and durability in tools like dental handpieces. The high-speed capability also makes it useful in lab equipment requiring consistent performance.

In consumer electronics, D/W R2 Bearing fits well in devices like small fans or printers, where its compact size and smooth operation are beneficial. The lightweight design helps maintain efficiency without adding bulk.
