Stainless Steel Deep Groove Ball Bearings D/W R2-5-2Z

Stainless Steel Deep Groove Ball Bearings D/W R2-5-2Z

The D/W R2-5-2Z is a compact stainless steel deep groove ball bearing, measuring just 0.125″ by 0.31252″ by 0.14059″. It’s designed for radial loads up to 72 lbf and can handle speeds up to 75,000 RPM.

Made entirely from stainless steel, including the cage, it offers good corrosion resistance and durability. The shielded design helps keep grease in and contaminants out, making it low-maintenance.

This bearing operates smoothly in temperatures from -30°C to 120°C, suitable for various environments. It’s interchangeable with SKF bearings, providing a reliable replacement option.

Ideal for small machinery or instruments where space is limited but performance is key. Compliant with RoHS and REACH standards, it’s a safe and practical choice.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number D/W R2-5-2Z
  • Brand TFL
  • Interchangeable SKF
  • Bore Dia 0.125"
  • Bore Dia Tolerance -0.00019" to 0.00019"
  • Outer Dia 0.31252"
  • Outer Dia Tolerance -0.0007" to -0.00031"
  • Width 0.14059"
  • Width Tolerance -0.005" to 0"
  • System of Measurement Inch
  • Bearing Type Ball
  • For Load Direction Radial
  • Construction Single Row
  • Seal Type Shielded
  • Tolerance Class P0
  • Radial Clearance Trade No CN
  • Ring Material Stainless Steel
  • Ball Material Stainless Steel
  • Cage Material Stainless Steel
  • Dynamic Radial Load 72 lbf
  • Static Radial Load 20 lbf
  • Temperature Range -30° to 120 °C
  • Lubrication Grease
  • RoHS Compliant
  • REACH Compliant
  • Max Speed 75000 rpm
  • Weight 0.000719 kg
Stainless Steel Deep Groove Ball Bearings D/W R2-5-2Z dimension drawing
Download DWG Download PDF

Features

Why Choose D/W R2-5-2Z Bearing for Precision Tasks?

D/W R2-5-2Z Bearing is crafted from stainless steel, offering excellent corrosion resistance and durability.

Its shielded design protects against contaminants, ensuring smooth operation in various environments.

With a dynamic radial load capacity of 72 lbf, it handles demanding applications with ease.

The bearing’s high-speed capability of 75,000 rpm makes it suitable for precision instruments.

Application

Common Applications of D/W R2-5-2Z Bearing
D/W R2-5-2Z Bearing is widely used in small electric motors, where its stainless steel construction ensures corrosion resistance and longevity. The shielded design keeps contaminants out, making it ideal for dusty environments.

In household appliances like food processors, D/W R2-5-2Z Bearing provides smooth rotation and low noise. Its compact inch size fits perfectly in tight spaces, ensuring reliable performance over time.

For medical devices such as dental tools, D/W R2-5-2Z Bearing offers precise movement and hygiene-friendly materials. The grease lubrication ensures quiet operation, which is essential in sensitive medical settings.

Automotive applications like dashboard controls benefit from D/W R2-5-2Z Bearing’s durability and resistance to temperature fluctuations. Its high-speed capability makes it a dependable choice for various vehicle components.
