Single Row Deep Groove Ball Bearings 6205 TC/C782

Single Row Deep Groove Ball Bearings 6205 TC/C782

The 6205 TC/C782 is a single row deep groove ball bearing with a 25mm bore and 52mm outer diameter, crafted from durable chrome steel. It handles radial loads up to 3147 lbf and spins smoothly at speeds up to 13000 RPM.

Its open design allows for easy lubrication, while the chrome steel cage ensures reliable performance. The bearing operates well in temperatures ranging from -30°C to 120°C.

This model is interchangeable with SKF bearings, making it a practical choice for replacements. Ideal for applications like electric motors or small machinery where radial loads are common.

Weighing just 128g, it’s lightweight yet sturdy for its size. Compliant with RoHS and REACH standards for safe and eco-friendly use.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number 6205 TC/C782
  • Brand TFL
  • Interchangeable SKF
  • System of Measurement Metric
  • For Load Direction Radial
  • Construction Single Row
  • Bearing Type Ball
  • Seal Type Open
  • Tolerance Class ABEC 1 | ISO P0
  • Radial Clearance Trade No CN
  • Bore Dia 25 mm
  • Bore Dia Tolerance -0.01mm to 0
  • Outer Dia 52 mm
  • Outer Dia Tolerance -0.013mm to 0
  • Width 15 mm
  • Width Tolerance -0.120mm to 0
  • Ring Material Chrome Steel
  • Ball Material Chrome Steel
  • Cage Material Chrome Steel
  • ROHS Compliant
  • REACH Compliant
  • Temperature Range -30°to 120 °C
  • Dynamic Radial Load 3147 lbf
  • Static Radial Load 1765 lbf
  • Max Speed 13000 rpm
  • Weight 128 g
  • price（$） 64.467
Single Row Deep Groove Ball Bearings 6205 TC/C782 dimension drawing
Download DWG Download PDF

Features

Performance Features of 6205 TC/C782 Bearing

6205 TC/C782 Bearing is built with chrome steel rings and balls, offering strong resistance to radial loads.
Its dynamic radial load capacity reaches 3147 lbf, ensuring reliable performance in various applications.
The chrome steel cage maintains ball alignment, reducing friction and extending service life.
With a maximum speed of 13,000 rpm, it delivers a balance of durability and efficiency.

Application

Industrial Uses of 6205 TC/C782 Bearing
This bearing is commonly used in conveyor systems and electric motors, where its radial load capacity ensures smooth operation. The open design allows for easy lubrication, extending service life in dusty environments.

Where Is 6205 TC/C782 Bearing Used?
You’ll find it in household appliances like washing machines, where its quiet performance and durability are key. The chrome steel construction also makes it suitable for light industrial machinery.

Built for Versatility: 6205 TC/C782 Bearing
It works well in automotive applications such as alternators, thanks to its balanced radial load handling. The ABEC 1 tolerance provides reliable performance without unnecessary precision costs.

Automotive vs Industrial: Applications of 6205 TC/C782 Bearing
In cars, it handles wheel hub loads effectively, while in factories it supports pump shafts. The 52mm outer diameter fits standard housings across both sectors.

Perfect Fit for Automation: 6205 TC/C782 Bearing
Robotic arms often use this bearing for joint movements due to its smooth rotation. The 13,000 rpm limit covers most automated production line requirements.
