Spherical Roller Thrust Bearings 29322 E

Spherical Roller Thrust Bearings 29322 E

The 29322 E is a spherical roller thrust bearing with a 110mm bore and 190mm outer diameter, built to handle combined loads. Its robust steel rollers and cage support dynamic thrust loads up to 137133 lbf, with a maximum speed of 3200 RPM.

The single-row design ensures stability, while the 2mm chamfer on the shaft washer aids smooth installation. It operates in temperatures from -30°C to 100°C, making it suitable for varied environments.

This bearing requires regular lubrication for optimal performance. Its interchangeable design with SKF bearings offers flexibility for replacements.

Weighing 5.3kg, it’s a sturdy choice for heavy-duty applications like industrial gearboxes or mining equipment. Compliant with RoHS and REACH standards for safety and environmental care.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number 29322 E
  • Brand TFL
  • Interchangeable SKF
  • Size 110 mm x 190 mm x 48 mm
  • Bore Dia 110 mm
  • Bore Dia Tolerance -0.015 to 0
  • Outer Dia 190 mm
  • Outer Dia Tolerance -0.03 to 0
  • Width 48 mm
  • Outside Diameter(d1) 171 mm
  • Shoulder Diameter Outer Ring (D1) 140 mm
  • Height Shaft Washer Cage(B1) 41.7 mm
  • Height Housing Washer(C) 24.8 mm
  • Distance From Shaft Washer End Side Face To Pressure Point(s) 63.8 mm
  • Chamfer Dimension Shaft Washer(r1,2) 2 mm
  • System of Measurement Metric
  • Roller Bearing Type Spherical
  • Bearing Type Roller
  • For Load Direction Combined
  • Construction Single Row
  • Roller Material Steel
  • Cage Material Steel
  • Dynamic Thrust Load 137133 lbf
  • Static Thrust Load 388919 lbf
  • Max Speed 3200 rpm
  • Lubrication Required
  • Temperature Range -30 to 100 °C
  • RoHS Compliant
  • REACH Compliant
  • Weight 5.3 kg
  • Width Shaft Washer Or Length Of Shaft(B) 30.3 mm
  • Price（$） 365.697

Features

How Is 29322 E Bearing Engineered for Reliability?

29322 E Bearing features a spherical roller design, allowing it to handle combined loads with ease.
Its steel rollers and cage provide robust support, ensuring durability under high thrust loads.

With a dynamic thrust load capacity of 137133 lbf, 29322 E Bearing performs reliably in demanding conditions.
The single-row construction simplifies installation while maintaining structural integrity.

29322 E Bearing operates smoothly within a temperature range of -30 to 100 °C.
Its precise dimensions and tolerances ensure consistent performance in various applications.

Application

Industrial Uses of 29322 E Bearing
29322 E Bearing is commonly used in heavy machinery like crushers and extruders, where its spherical roller design handles combined loads with ease. The steel construction ensures durability even in demanding industrial environments.

Where Is 29322 E Bearing Used?
You’ll often find 29322 E Bearing in mining equipment, where its high dynamic thrust load capacity keeps operations running smoothly. Its metric sizing makes it a versatile choice for various global applications.

Built for Heavy-Duty Use: 29322 E Bearing
29322 E Bearing excels in construction equipment, supporting components like gearboxes and hydraulic systems. The steel cage and rollers provide reliable performance under extreme conditions.

Automotive vs Aerospace: Applications of 29322 E Bearing
In automotive systems, 29322 E Bearing supports heavy-duty transmissions, while in aerospace, it’s used in landing gear mechanisms. Its temperature range and load capacity make it adaptable across industries.

Practical Applications of 29322 E Bearing
29322 E Bearing is a go-to for wind turbines, where its ability to handle misalignment and heavy loads is crucial. The lubrication requirement ensures long-term performance in high-speed rotations.
